Part Symbol
-
Footprint
-
3D Model
Available Download Formats
By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy
DATACOM, LAN SWITCHING CIRCUIT, PQFP128
Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.
Part # | Distributor | Description | Stock | Price | Buy | |
---|---|---|---|---|---|---|
DISTI #
70Y9045
|
Newark | Enet Controller, -40 To 85Deg C, Device Type:Ethernet Switch, Supported Standards:Ieee 802.3, Ieee 802.3U, Supply Voltage Min:3.15V, Supply Voltage Max:3.45V, Ic Case/Package:Pqfp, No. Of Pins:128Pins, Ic Mounting:Surface Mount Rohs Compliant: Yes |Microchip KSZ8995MAI Min Qty: 1 Package Multiple: 1 Date Code: 1 Container: Bulk | 93 |
|
$13.2500 / $16.4500 | Buy Now |
DISTI #
27AC7182
|
Newark | Pqfp 5-Port 10/100 Switch W/ Transceivers & Frame Buffers Rohs Compliant: Yes |Microchip KSZ8995MAI Min Qty: 1 Package Multiple: 1 Date Code: 0 Container: Bulk | 0 |
|
$11.9700 / $15.8200 | Buy Now |
DISTI #
576-2126-ND
|
DigiKey | IC 10/100 INTEG SWITCH 128PQFP Min Qty: 1 Lead time: 4 Weeks Container: Tray |
2764 In Stock |
|
$12.7375 / $15.8200 | Buy Now |
DISTI #
KSZ8995MAI
|
Avnet Americas | Ethernet Switch 5-Port 100Mbps 128-Pin PQFP - Trays (Alt: KSZ8995MAI) RoHS: Compliant Min Qty: 66 Package Multiple: 1 Lead time: 4 Weeks, 0 Days Container: Tray | 71 |
|
$11.9700 / $15.8200 | Buy Now |
DISTI #
70Y9045
|
Avnet Americas | Ethernet Switch 5-Port 100Mbps 128-Pin PQFP - Bulk (Alt: 70Y9045) RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 14 Weeks, 4 Days Container: Bulk | 93 Partner Stock |
|
$13.4800 / $16.4500 | Buy Now |
DISTI #
998-KSZ8995MAI
|
Mouser Electronics | Ethernet ICs 5-Port 10/100 Switch w/ Transceivers & Frame Buffers RoHS: Compliant | 1091 |
|
$12.7400 / $15.8200 | Buy Now |
DISTI #
E54:1762_00013126
|
Arrow Electronics | Ethernet Switch 5-Port 100Mbps 128-Pin PQFP Tray RoHS: Compliant Min Qty: 66 Package Multiple: 66 Lead time: 4 Weeks Date Code: 2342 | Europe - 10296 |
|
$12.0800 / $12.2400 | Buy Now |
DISTI #
V99:2348_07457826
|
Arrow Electronics | Ethernet Switch 5-Port 100Mbps 128-Pin PQFP Tray RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 4 Weeks Date Code: 2340 | Americas - 300 |
|
$13.6800 / $15.6400 | Buy Now |
DISTI #
VBF:5286_07457826
|
Arrow Electronics | Ethernet Switch 5-Port 100Mbps 128-Pin PQFP Tray RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 4 Weeks Date Code: 2335 | Americas - 30 |
|
$13.0700 / $15.3700 | Buy Now |
DISTI #
KSZ8995MAI
|
Microchip Technology Inc | 5-Port 10/100 Switch w/ Transceivers & Frame Buffers, Projected EOL: 2048-10-03 RoHS: Compliant pbFree: Yes | 55649 |
|
$10.4800 / $15.8200 | Buy Now |
By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy
|
KSZ8995MAI
Microchip Technology Inc
Buy Now
Datasheet
|
Compare Parts:
KSZ8995MAI
Microchip Technology Inc
DATACOM, LAN SWITCHING CIRCUIT, PQFP128
|
Rohs Code | Yes | |
Part Life Cycle Code | Active | |
Ihs Manufacturer | MICROCHIP TECHNOLOGY INC | |
Package Description | PQFP-128 | |
Reach Compliance Code | compliant | |
ECCN Code | EAR99 | |
HTS Code | 8517.70.00.00 | |
Factory Lead Time | 14 Weeks, 4 Days | |
Samacsys Manufacturer | Microchip | |
JESD-30 Code | R-PQFP-G128 | |
JESD-609 Code | e3 | |
Length | 20 mm | |
Moisture Sensitivity Level | 1 | |
Number of Functions | 1 | |
Number of Terminals | 128 | |
Operating Temperature-Max | 85 °C | |
Operating Temperature-Min | -40 °C | |
Package Body Material | PLASTIC/EPOXY | |
Package Code | FQFP | |
Package Equivalence Code | QFP128,.68X.91,20 | |
Package Shape | RECTANGULAR | |
Package Style | FLATPACK, FINE PITCH | |
Peak Reflow Temperature (Cel) | 260 | |
Seated Height-Max | 3.4 mm | |
Supply Current-Max | 230 mA | |
Supply Voltage-Nom | 1.8 V | |
Surface Mount | YES | |
Technology | CMOS | |
Telecom IC Type | ETHERNET SWITCH | |
Temperature Grade | INDUSTRIAL | |
Terminal Finish | MATTE TIN | |
Terminal Form | GULL WING | |
Terminal Pitch | 0.5 mm | |
Terminal Position | QUAD | |
Width | 14 mm |
This table gives cross-reference parts and alternative options found for KSZ8995MAI. The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of KSZ8995MAI, but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.
Part Number | Description | Manufacturer | Compare |
---|---|---|---|
KS8995MAI | LAN Switching Circuit, CMOS, PQFP128 | Microchip Technology Inc | KSZ8995MAI vs KS8995MAI |
KS8995FQ | DATACOM, LAN SWITCHING CIRCUIT, PQFP128 | Microchip Technology Inc | KSZ8995MAI vs KS8995FQ |
KS8995MA | LAN Switching Circuit, CMOS, PQFP128 | Microchip Technology Inc | KSZ8995MAI vs KS8995MA |
KSZ8995FQI | DATACOM, LAN SWITCHING CIRCUIT, PQFP128 | Microchip Technology Inc | KSZ8995MAI vs KSZ8995FQI |
