MAX14932AASE+T Information
MAX14932AASE+T by Analog Devices Inc is an Other Interface IC.
Other Interface ICs are under the broader part category of Drivers And Interfaces.
A driver controls the current or voltage delivered to components like LCDs or motors, while an interface component connects systems for data transfer and control. Read more about Drivers And Interfaces on our Drivers And Interfaces part category page.
Price & Stock for MAX14932AASE+T
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
700-MAX14932AASE+T
|
Mouser Electronics | Digital Isolators 4 channel (2/2 config.), 1Mbps, 2.5kVrms RoHS: Compliant | 0 |
|
$2.3600 | Order Now |
|
|
Analog Devices Inc | 4 channel (2/2 config.), 1Mbps Min Qty: 2500 Package Multiple: 1 | 0 |
|
$1.8900 / $2.3625 | Buy Now |
|
|
Vyrian | Interface ICs | 948 |
|
RFQ |
Part Details for MAX14932AASE+T
MAX14932AASE+T CAD Models
MAX14932AASE+T Part Data Attributes
|
|
MAX14932AASE+T
Analog Devices Inc
Buy Now
Datasheet
|
Compare Parts:
MAX14932AASE+T
Analog Devices Inc
4-Channel, 1kVRMS, and 2.75kVRMS, Digital Isolators, 16-SOIC_N-150_MIL, 16 Pins, -40 to 125C
Select a part to compare: |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | ANALOG DEVICES INC | |
| Part Package Code | 16-SOIC_N-150_MIL | |
| Pin Count | 16 | |
| Manufacturer Package Code | 16-SOIC_N-150_MIL | |
| Date Of Intro | 2014-10-24 | |
| Samacsys Manufacturer | Analog Devices | |
| Additional Feature | Also has VDDB supply from 1.71V to 5.5V | |
| Interface IC Type | INTERFACE CIRCUIT | |
| JESD-30 Code | R-PDSO-G16 | |
| JESD-609 Code | e3 | |
| Length | 9.9 mm | |
| Moisture Sensitivity Level | 1 | |
| Number of Functions | 4 | |
| Number of Terminals | 16 | |
| Operating Temperature-Max | 125 °C | |
| Operating Temperature-Min | -40 °C | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | SOP | |
| Package Equivalence Code | SOP16,.25 | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE | |
| Peak Reflow Temperature (Cel) | 260 | |
| Seated Height-Max | 1.75 mm | |
| Supply Voltage-Max | 5.5 V | |
| Supply Voltage-Min | 1.71 V | |
| Supply Voltage-Nom | 3.3 V | |
| Surface Mount | YES | |
| Technology | BICMOS | |
| Terminal Finish | Matte Tin (Sn) | |
| Terminal Form | GULL WING | |
| Terminal Pitch | 1.27 mm | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Width | 3.9 mm |
