5 V, Slew-Rate Limited, Low Power, 250 kbps, Full Duplex EIA RS-485 Transceiver (with DE/RE)

Part Details for ADM489ABRZ-REEL7 by Analog Devices Inc

Results Overview of ADM489ABRZ-REEL7 by Analog Devices Inc

Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.

ADM489ABRZ-REEL7 Information

ADM489ABRZ-REEL7 by Analog Devices Inc is a Line Driver or Receiver.
Line Driver or Receivers are under the broader part category of Drivers And Interfaces.

A driver controls the current or voltage delivered to components like LCDs or motors, while an interface component connects systems for data transfer and control. Read more about Drivers And Interfaces on our Drivers And Interfaces part category page.

Price & Stock for ADM489ABRZ-REEL7

Part # Distributor Description Stock Price Buy
DISTI # 505-ADM489ABRZ-REEL7CT-ND
DigiKey IC TRANSCEIVER FULL 1/1 14SOIC Min Qty: 1 Lead time: 10 Weeks Container: Digi-Reel®, Cut Tape (CT), Tape & Reel (TR) 547
In Stock
  • 1 $3.2100
  • 10 $2.4100
  • 25 $2.2092
  • 100 $1.9884
  • 250 $1.8832
  • 500 $1.8198
  • 1,000 $1.7676
  • 2,000 $1.7246
  • 3,000 $1.7031
  • 5,000 $1.6793
$1.6793 / $3.2100 Buy Now
DISTI # 584-ADM489ABRZ-R7
Mouser Electronics RS-422/RS-485 Interface IC 5V 250kbps Full Duplex RS485 Trans IC RoHS: Compliant 15
  • 1 $4.5600
  • 10 $2.9600
  • 25 $2.5400
  • 100 $2.0700
  • 250 $1.8300
  • 500 $1.6900
  • 1,000 $1.5600
$1.5600 / $4.5600 Buy Now
Analog Devices Inc 5V 250kbps Full Duplex RS485 T Min Qty: 1 Package Multiple: 1000 2110
  • 1 $4.5600
  • 10 $2.9520
  • 25 $2.5340
  • 100 $2.0609
  • 250 $1.8287
  • 500 $1.6858
  • 1,000 $1.5662
  • 2,000 $1.5625
$1.5625 / $4.5600 Buy Now
DISTI # 58802519
Verical Single Transmitter/Receiver RS-422/RS-485 14-Pin SOIC N T/R RoHS: Compliant Min Qty: 1000 Package Multiple: 1000 Americas - 2000
  • 1,000 $1.7857
$1.7857 Buy Now
Rochester Electronics ADM489 - Full-Duplex, Low Power, Slew Rate Limited, EIA RS-485 Transceiver RoHS: Compliant Status: Active Min Qty: 1 8994
  • 1 $1.7400
  • 25 $1.7100
  • 100 $1.6400
  • 500 $1.5700
  • 1,000 $1.4800
$1.4800 / $1.7400 Buy Now
Win Source Electronics IC TRANSCEIVER FULL 1/1 14SOIC / 1/1 Transceiver Full RS422, RS485 14-SOIC 283
  • 11 $4.9237
  • 25 $4.0400
  • 39 $3.9138
  • 53 $3.7875
  • 69 $3.6613
  • 92 $3.2825
$3.2825 / $4.9237 Buy Now

Part Details for ADM489ABRZ-REEL7

ADM489ABRZ-REEL7 CAD Models

  • Part Symbol

    Part Symbol

  • Footprint

    footprint

  • 3D Model

    3D Model

Available Download Formats

Sign in to download CAD models Register or Sign In

By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy

ADM489ABRZ-REEL7 Part Data Attributes

Parametric Data
ADM489ABRZ-REEL7 Analog Devices Inc
Buy Now Datasheet
Compare Parts:
ADM489ABRZ-REEL7 Analog Devices Inc 5 V, Slew-Rate Limited, Low Power, 250 kbps, Full Duplex EIA RS-485 Transceiver (with DE/RE)
Select a part to compare:
Pbfree Code No
Rohs Code Yes
Part Life Cycle Code Active
Ihs Manufacturer ANALOG DEVICES INC
Part Package Code SOIC
Package Description ROHS COMPLIANT, MS-012AB, SOIC-14
Pin Count 14
Manufacturer Package Code R-14
Reach Compliance Code compliant
ECCN Code EAR99
HTS Code 8542.39.00.01
Samacsys Manufacturer Analog Devices
Differential Output YES
Driver Number of Bits 1
Input Characteristics DIFFERENTIAL SCHMITT TRIGGER
Interface IC Type LINE TRANSCEIVER
Interface Standard EIA-485-A; TIA-485-A; EIA-422; ISO 8482E
JESD-30 Code R-PDSO-G14
JESD-609 Code e3
Length 8.65 mm
Moisture Sensitivity Level 1
Number of Functions 1
Number of Terminals 14
Operating Temperature-Max 85 °C
Operating Temperature-Min -40 °C
Out Swing-Min 1.5 V
Output Low Current-Max 0.004 A
Package Body Material PLASTIC/EPOXY
Package Code SOP
Package Equivalence Code SOP14,.25
Package Shape RECTANGULAR
Package Style SMALL OUTLINE
Peak Reflow Temperature (Cel) 260
Qualification Status Not Qualified
Receive Delay-Max 2000 ns
Receiver Number of Bits 1
Seated Height-Max 1.75 mm
Supply Current-Max 0.074 mA
Supply Voltage-Max 5.5 V
Supply Voltage-Min 4.5 V
Supply Voltage-Nom 5 V
Surface Mount YES
Technology BICMOS
Temperature Grade INDUSTRIAL
Terminal Finish Matte Tin (Sn)
Terminal Form GULL WING
Terminal Pitch 1.27 mm
Terminal Position DUAL
Time@Peak Reflow Temperature-Max (s) 30
Transmit Delay-Max 2000 ns
Width 3.9 mm
