Consumer Circuits Audio/Video Amplifiers SSM2517CBZ-RL

SSM2517CBZ-RL
Analog Devices Inc
Description: PDM Digital Input, Mono 2.4 W Class-D Audio Amplifier

Overview of SSM2517CBZ-RL by Analog Devices Inc

Note: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.
  • Distributor Offerings: ( 5 listings )
  • Number of FFF Equivalents: ( 0 replacements )
  • CAD Models: ( Request Part )
  • Number of Functional Equivalents: ( 0 options )
  • Part Data Attributes ( Available )
  • Reference Designs: ( Not Available )
Where used in Applications: Education and Research Industrial Automation Electronic Manufacturing

Available Datasheets

Part # Manufacturer Description Datasheet
SSM2517CBZ-RL Analog Devices Digital PDM-Input Mono 2.4W Cl
SSM2517CBZ-R7 Analog Devices Digital PDM-Input Mono 2.4W Cl

Price & Stock for SSM2517CBZ-RL by Analog Devices Inc

Part # Manufacturer Description Stock Price Buy
DISTI # 2156-SSM2517CBZ-RL-ND
DigiKey IC AMP CLASS D MONO 2.4W 9WLCSP Min Qty: 233 Lead time: 10 Weeks Container: Bulk MARKETPLACE PRODUCT 10000
In Stock
  • 233 $1.2900
$1.2900 Buy Now
DISTI # SSM2517CBZ-RL-ND
DigiKey IC AMP CLASS D MONO 2.4W 9WLCSP Min Qty: 233 Lead time: 10 Weeks Container: Tape & Reel (TR) Temporarily Out of Stock
  • 10,000 $1.1125
$1.1125 Buy Now
DISTI # 584-SSM2517CBZ-R
Mouser Electronics Audio Amplifiers Digital PDM-Input Mono 2.4W ClassD RoHS: Compliant 0
  • 10,000 $1.1100
$1.1100 Order Now
DISTI # 77891585
Verical Audio Amp Speaker 1-CH Mono 2.4W Class-D 9-Pin WLCSP T/R RoHS: Compliant Min Qty: 10000 Package Multiple: 10000 Americas - 20000
  • 10,000 $1.0680
$1.0680 Buy Now
Rochester Electronics PDM Digital Input, Mono 2.4W CLASS-D Audio Amplifier RoHS: Compliant Status: Active Min Qty: 1 10000
  • 1 $1.3000
  • 25 $1.2700
  • 100 $1.2200
  • 500 $1.1700
  • 1,000 $1.1000
$1.1000 / $1.3000 Buy Now

CAD Models for SSM2517CBZ-RL by Analog Devices Inc
You need to Sign In or Sign Up to download CAD models.

There are no models available for this part yet.

Part Data Attributes for SSM2517CBZ-RL by Analog Devices Inc
Parametric Data

SSM2517CBZ-RL
Analog Devices Inc
Buy Now
-
-
Pbfree Code
No
Rohs Code
Yes
Part Life Cycle Code
Not Recommended
Ihs Manufacturer
ANALOG DEVICES INC
Pin Count
9
Manufacturer Package Code
CB-9-2
Reach Compliance Code
compliant
Samacsys Manufacturer
Analog Devices
Consumer IC Type
CLASS D AUDIO AMPLIFIER
JESD-30 Code
S-PBGA-B9
JESD-609 Code
e1
Moisture Sensitivity Level
1
Number of Functions
1
Number of Terminals
9
Operating Temperature-Max
85 °C
Operating Temperature-Min
-40 °C
Package Body Material
PLASTIC/EPOXY
Package Code
FBGA
Package Equivalence Code
BGA9,3X3,20
Package Shape
SQUARE
Package Style
GRID ARRAY, FINE PITCH
Peak Reflow Temperature (Cel)
260
Qualification Status
Not Qualified
Surface Mount
YES
Technology
CMOS
Temperature Grade
INDUSTRIAL
Terminal Finish
Tin/Silver/Copper (Sn/Ag/Cu)
Terminal Form
BALL
Terminal Pitch
0.5 mm
Terminal Position
BOTTOM
Time@Peak Reflow Temperature-Max (s)
NOT SPECIFIED
