Resistors / Fixed Resistors / SR10-0.50-1%
Datasheets
SR10-0.50-1% by: Caddock Electronics Inc

Fixed Resistor, 1W, 0.5ohm, 1% +/-Tol, 100ppm/Cel, Through Hole Mount, 3709, RADIAL LEADED-4

Part Details for SR10-0.50-1% by Caddock Electronics Inc

Results Overview of SR10-0.50-1% by Caddock Electronics Inc

Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.

Applications Consumer Electronics Energy and Power Systems Transportation and Logistics Renewable Energy Automotive

SR10-0.50-1% Information

SR10-0.50-1% by Caddock Electronics Inc is a Fixed Resistor.
Fixed Resistors are under the broader part category of Resistors.

Resistors are passive components that work by limiting electron flow in a circuit. They are available as fixed or as variable (potentionmeters). Read more about Resistors on our Resistors part category page.

Price & Stock for SR10-0.50-1%

Part # Distributor Description Stock Price Buy
DISTI # 41AK2405
Newark Res, R5, 1%, 1W, Radial, Thick Film, Resistance:0.5Ohm, Product Range:Sr Series, Power Rating:1W,... Resistor Technology:Thick Film, Resistor Case/Package:Radial Leaded, Resistance Tolerance:± 1%, Product Length:2.29Mm Rohs Compliant: Yes |Caddock SR10-0.50-1% more RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 1 Container: Cut Tape 100
  • 1 $5.5300
  • 10 $5.2700
  • 25 $5.1100
  • 50 $4.3300
$4.3300 / $5.5300 Buy Now
DISTI # 25H9849
Newark Current Sense Resistor, 0.5 Ohm, 1W, 1%, Full Reel, Resistance:0.5Ohm, Product Range:Sr Series, P... ower Rating:1W, Resistor Technology:Thick Film, Resistor Case/Package:-, Resistance Tolerance:± 1%, Product Length:9.27Mm Rohs Compliant: Yes |Caddock SR10-0.50-1% more RoHS: Compliant Min Qty: 50 Package Multiple: 1 Date Code: 0 Container: Reel 0
  • 1 $4.1300
  • 2,000 $3.9300
  • 4,000 $3.6500
  • 8,000 $3.4000
  • 12,000 $3.2800
  • 20,000 $3.2300
$3.2300 / $4.1300 Buy Now
DISTI # 683-SR10-0.50-1%CT-ND
DigiKey RES 0.5 OHM 1% 1W SR10 Min Qty: 1 Lead time: 19 Weeks Container: Cut Tape (CT), Tape & Reel (TR) 450
In Stock
  • 1 $8.4700
  • 10 $5.8300
  • 25 $5.1160
  • 50 $4.6688
  • 100 $4.2888
  • 250 $3.8726
  • 500 $3.6124
  • 750 $3.4787
  • 1,250 $3.3276
  • 1,750 $3.2375
  • 2,500 $3.1495
$3.1495 / $8.4700 Buy Now
DISTI # 684-SR10-0.5
Mouser Electronics Current Sense Resistors - Through Hole 0.5 ohm 1W 1% CURRENT SENSE RoHS: Compliant 62
  • 1 $6.8700
  • 10 $4.7000
  • 50 $4.4000
  • 100 $3.8200
  • 500 $3.4700
  • 1,000 $3.2300
  • 2,000 $3.1400
$3.1400 / $6.8700 Buy Now
DISTI # 70089485
RS Resistor, Film, Current Sense, Kelvin Leads, 500 milliohm, 1%, 1W Min Qty: 1 Package Multiple: 1 Lead time: 12 Weeks, 0 Days Container: Bulk 50
  • 1 $5.5900
  • 5 $5.3100
  • 10 $5.0300
  • 20 $4.7500
$4.7500 / $5.5900 Buy Now

Part Details for SR10-0.50-1%

SR10-0.50-1% CAD Models

  • Part Symbol

    Part Symbol

  • Footprint

    footprint

  • 3D Model

    3D Model

Available Download Formats

Sign in to download CAD models Register or Sign In

By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy

SR10-0.50-1% Part Data Attributes

Parametric Data
SR10-0.50-1% Caddock Electronics Inc
Buy Now Datasheet
Compare Parts:
SR10-0.50-1% Caddock Electronics Inc Fixed Resistor, 1W, 0.5ohm, 1% +/-Tol, 100ppm/Cel, Through Hole Mount, 3709, RADIAL LEADED-4
Select a part to compare:
Pbfree Code Yes
Rohs Code Yes
Part Life Cycle Code Active
Ihs Manufacturer CADDOCK ELECTRONICS INC
Package Description RADIAL LEADED-4
Reach Compliance Code compliant
ECCN Code EAR99
Samacsys Manufacturer Caddock
Construction Rectangular
Lead Length 3.18 mm
Mounting Feature THROUGH HOLE MOUNT
Number of Terminals 4
Operating Temperature-Max 150 °C
Package Height 9.4 mm
Package Length 9.27 mm
Package Shape RECTANGULAR PACKAGE
Package Style SIP
Package Width 2.29 mm
Rated Power Dissipation (P) 1 W
Rated Temperature 70 °C
Resistance 0.5 Ω
Resistor Type FIXED RESISTOR
Surface Mount NO
Technology METAL GLAZE/THICK FILM
Temperature Coefficient -50,100 ppm/°C
Terminal Shape FLAT
Tolerance 1%

SR10-0.50-1% Frequently Asked Questions (FAQ)

  • The recommended power rating for the SR10-0.50-1% is 1 watt, but it can handle up to 2 watts for short periods of time.

  • The SR10-0.50-1% is suitable for high-frequency applications up to 100 MHz, but its performance may degrade above 50 MHz due to parasitic inductance and capacitance.

  • The SR10-0.50-1% is rated for operation up to 150°C, but its accuracy and stability may degrade above 125°C. It's recommended to derate the power rating at higher temperatures.

  • The SR10-0.50-1% is designed to withstand moderate vibration levels, but it's not recommended for extreme vibration environments. It's recommended to use additional mechanical support or mounting methods to ensure reliability.

  • Yes, the SR10-0.50-1% is compatible with lead-free soldering processes, but it's recommended to follow the manufacturer's recommended soldering profile to ensure reliability.
