SN74LVCH16374ADL Information
SN74LVCH16374ADL by Texas Instruments is a Bus Driver/Transceiver.
Bus Driver/Transceivers are under the broader part category of Logic Components.
Digital logic governs the behavior of signals in electronic circuits, enabling complex decisions based on simple binary inputs (yes/no). Logic components perform operations from these signals. Read more about Logic Components on our Logic part category page.
Price & Stock for SN74LVCH16374ADL
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
2156-SN74LVCH16374ADL-ND
|
DigiKey | IC FF D-TYPE DUAL 8BIT 48SSOP Min Qty: 1 Lead time: 6 Weeks Container: Bulk MARKETPLACE PRODUCT |
29338 In Stock |
|
$0.6600 | Buy Now |
|
DISTI #
296-8589-5-ND
|
DigiKey | IC FF D-TYPE DUAL 8BIT 48SSOP Min Qty: 1 Lead time: 6 Weeks Container: Tube |
415 In Stock |
|
$0.6253 / $1.3100 | Buy Now |
|
DISTI #
595-SN74LVCH16374ADL
|
Mouser Electronics | Flip Flops Tri-State 16bit A 595-SNLVCH16374ADLR RoHS: Compliant | 36 |
|
$0.6000 / $1.3100 | Buy Now |
|
DISTI #
86027990
|
Verical | Flip Flop D-Type Bus Interface Pos-Edge 3-ST 2-Element 48-Pin SSOP Tube RoHS: Compliant Min Qty: 527 Package Multiple: 1 Date Code: 9901 | Americas - 14584 |
|
$0.6729 / $0.7125 | Buy Now |
|
DISTI #
86041105
|
Verical | Flip Flop D-Type Bus Interface Pos-Edge 3-ST 2-Element 48-Pin SSOP Tube RoHS: Compliant Min Qty: 527 Package Multiple: 1 Date Code: 0401 | Americas - 5328 |
|
$0.6729 / $0.7125 | Buy Now |
|
DISTI #
86026701
|
Verical | Flip Flop D-Type Bus Interface Pos-Edge 3-ST 2-Element 48-Pin SSOP Tube RoHS: Compliant Min Qty: 527 Package Multiple: 1 Date Code: 0001 | Americas - 3625 |
|
$0.6729 / $0.7125 | Buy Now |
|
DISTI #
86040246
|
Verical | Flip Flop D-Type Bus Interface Pos-Edge 3-ST 2-Element 48-Pin SSOP Tube RoHS: Compliant Min Qty: 527 Package Multiple: 1 | Americas - 1775 |
|
$0.6729 / $0.7125 | Buy Now |
|
DISTI #
86037405
|
Verical | Flip Flop D-Type Bus Interface Pos-Edge 3-ST 2-Element 48-Pin SSOP Tube RoHS: Compliant Min Qty: 527 Package Multiple: 1 Date Code: 1001 | Americas - 1550 |
|
$0.6729 / $0.7125 | Buy Now |
|
DISTI #
86041257
|
Verical | Flip Flop D-Type Bus Interface Pos-Edge 3-ST 2-Element 48-Pin SSOP Tube RoHS: Compliant Min Qty: 527 Package Multiple: 1 Date Code: 0501 | Americas - 1550 |
|
$0.6729 / $0.7125 | Buy Now |
|
DISTI #
86025648
|
Verical | Flip Flop D-Type Bus Interface Pos-Edge 3-ST 2-Element 48-Pin SSOP Tube RoHS: Compliant Min Qty: 527 Package Multiple: 1 Date Code: 1301 | Americas - 575 |
|
$0.6729 / $0.7125 | Buy Now |
Part Details for SN74LVCH16374ADL
SN74LVCH16374ADL CAD Models
SN74LVCH16374ADL Part Data Attributes
|
|
SN74LVCH16374ADL
Texas Instruments
Buy Now
Datasheet
|
Compare Parts:
SN74LVCH16374ADL
Texas Instruments
16-Bit Edge-Triggered D-Type Flip-Flop With 3-State Outputs 48-SSOP -40 to 125
Select a part to compare: |
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | TEXAS INSTRUMENTS INC | |
| Part Package Code | SSOP | |
| Package Description | SSOP-48 | |
| Pin Count | 48 | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.39.00.01 | |
| Samacsys Manufacturer | Texas Instruments | |
| Control Type | INDEPENDENT CONTROL | |
| Count Direction | UNIDIRECTIONAL | |
| Family | LVC/LCX/Z | |
| JESD-30 Code | R-PDSO-G48 | |
| JESD-609 Code | e4 | |
| Length | 15.875 mm | |
| Load Capacitance (CL) | 50 pF | |
| Logic IC Type | BUS DRIVER | |
| Max Frequency@Nom-Sup | 150000000 Hz | |
| Max I(ol) | 0.024 A | |
| Moisture Sensitivity Level | 1 | |
| Number of Bits | 8 | |
| Number of Functions | 16 | |
| Number of Ports | 2 | |
| Number of Terminals | 48 | |
| Operating Temperature-Max | 125 °C | |
| Operating Temperature-Min | -40 °C | |
| Output Characteristics | 3-STATE | |
| Output Polarity | TRUE | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | SSOP | |
| Package Equivalence Code | SSOP48,.4 | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE, SHRINK PITCH | |
| Packing Method | TUBE | |
| Peak Reflow Temperature (Cel) | 260 | |
| Power Supply Current-Max (ICC) | 0.02 mA | |
| Prop. Delay@Nom-Sup | 4.5 ns | |
| Propagation Delay (tpd) | 4.9 ns | |
| Qualification Status | Not Qualified | |
| Seated Height-Max | 2.79 mm | |
| Supply Voltage-Max (Vsup) | 3.6 V | |
| Supply Voltage-Min (Vsup) | 1.65 V | |
| Supply Voltage-Nom (Vsup) | 3.3 V | |
| Surface Mount | YES | |
| Technology | CMOS | |
| Temperature Grade | AUTOMOTIVE | |
| Terminal Finish | Nickel/Palladium/Gold (Ni/Pd/Au) | |
| Terminal Form | GULL WING | |
| Terminal Pitch | 0.635 mm | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Trigger Type | POSITIVE EDGE | |
| Width | 7.49 mm |
Alternate Parts for SN74LVCH16374ADL
This table gives cross-reference parts and alternative options found for SN74LVCH16374ADL. The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of SN74LVCH16374ADL, but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.
| Part Number | Manufacturer | Composite Price | Description | Compare |
|---|---|---|---|---|
| SN74LVCH16541ADLG4 | Texas Instruments | Check for Price | 16-ch, 1.65-V to 3.6-V buffers with bus-hold and 3-state outputs 48-SSOP -40 to 85 | SN74LVCH16374ADL vs SN74LVCH16541ADLG4 |
| QS74LCX16374CPV | Quality Semiconductor Inc | Check for Price | Bus Driver, LVC/LCX/Z Series, 2-Func, 8-Bit, True Output, CMOS, PDSO48, | SN74LVCH16374ADL vs QS74LCX16374CPV |
| IDT74LVCH16541APV8 | Integrated Device Technology Inc | Check for Price | Bus Driver, LVC/LCX/Z Series, 2-Func, 8-Bit, True Output, CMOS, PDSO48, 0.635 MM PITCH, SSOP-48 | SN74LVCH16374ADL vs IDT74LVCH16541APV8 |
| 74LCX16374MEA | Fairchild Semiconductor Corporation | Check for Price | Bus Driver, LVC/LCX/Z Series, 2-Func, 8-Bit, True Output, CMOS, PDSO48, 0.300 INCH, MO-118, SSOP-48 | SN74LVCH16374ADL vs 74LCX16374MEA |
| 74LCXH16374MEA | Rochester Electronics LLC | Check for Price | Bus Driver, LVC/LCX/Z Series, 2-Func, 8-Bit, True Output, CMOS, PDSO48, 0.300 INCH, MO-118, SSOP-48 | SN74LVCH16374ADL vs 74LCXH16374MEA |
| 74LVCH16374APV | Integrated Device Technology Inc | Check for Price | D Flip-Flop, LVC/LCX/Z Series, 2-Func, 8-Bit, True Output, CMOS, PDSO48, SSOP-48 | SN74LVCH16374ADL vs 74LVCH16374APV |
| IDT74LVC16541APV8 | Integrated Device Technology Inc | Check for Price | Bus Driver, LVC/LCX/Z Series, 2-Func, 8-Bit, True Output, CMOS, PDSO48, 0.635 MM PITCH, SSOP-48 | SN74LVCH16374ADL vs IDT74LVC16541APV8 |
| SN74LVC16374ADLR | Texas Instruments | $0.7713 | 16-Bit Edge-Triggered D-Type Flip-Flop With 3-State Outputs 48-SSOP -40 to 125 | SN74LVCH16374ADL vs SN74LVC16374ADLR |
| SN74LVCH16541ADL | Texas Instruments | $0.9181 | 16-ch, 1.65-V to 3.6-V buffers with bus-hold and 3-state outputs 48-SSOP -40 to 85 | SN74LVCH16374ADL vs SN74LVCH16541ADL |
