Resistors / Metal Film Resistors / RNF12FBD475K
Datasheets
RNF12FBD475K by: SEI Stackpole Electronics Inc

Fixed Resistor, Metal Film, 0.5W, 475000ohm, 350V, 1% +/-Tol, 100ppm/Cel, Through Hole Mount, AXIAL LEADED, ROHS COMPLIANT

Part Details for RNF12FBD475K by SEI Stackpole Electronics Inc

Results Overview of RNF12FBD475K by SEI Stackpole Electronics Inc

Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.

Applications Industrial Automation Renewable Energy Robotics and Drones

RNF12FBD475K Information

RNF12FBD475K by SEI Stackpole Electronics Inc is a Metal Film Resistor.
Metal Film Resistors are under the broader part category of Resistors.

Resistors are passive components that work by limiting electron flow in a circuit. They are available as fixed or as variable (potentionmeters). Read more about Resistors on our Resistors part category page.

Price & Stock for RNF12FBD475K

Part # Distributor Description Stock Price Buy
DISTI # 738-RNF12FBD475K-ND
DigiKey RES 475K OHM 1% 1/2W AXIAL Min Qty: 1000 Lead time: 22 Weeks Container: Bulk Temporarily Out of Stock
  • 1,000 $0.0309
$0.0309 Buy Now
DISTI # RNF12FBD475K
Avnet Americas Res Metal Film 475K Ohm 1% 1/2W ?100ppm/?C Conformal AXL Thru-Hole Bulk - Bulk (Alt: RNF12FBD475K) RoHS: Compliant Min Qty: 1000 Package Multiple: 1000 Lead time: 22 Weeks, 0 Days Container: Bulk 0
  • 1,000 $0.0318
  • 2,000 $0.0313
  • 4,000 $0.0307
  • 6,000 $0.0302
  • 8,000 $0.0297
$0.0297 / $0.0318 Buy Now
DISTI # 708-RNF12FBD475K
Mouser Electronics Metal Film Resistors - Through Hole RES, MF, 1/2W, 475 Kohm, 1%, 100 ppm RoHS: Compliant 0
  • 1,000 $0.0300
$0.0300 Order Now
Onlinecomponents.com   RoHS: Compliant 0
  • 1,000 $0.0374
  • 2,000 $0.0355
  • 4,000 $0.0337
  • 8,000 $0.0321
$0.0321 / $0.0374 Buy Now
NAC RESISTOR, METAL FILM, 1/2W, 475 Kohm, 1%, 100 ppm - Metal Film Resistor - Standard RoHS: Compliant Min Qty: 1000 Package Multiple: 1000 0
  • 1,000 $0.0830
  • 5,000 $0.0710
  • 25,000 $0.0625
$0.0625 / $0.0830 Buy Now

Part Details for RNF12FBD475K

RNF12FBD475K Part Data Attributes

Parametric Data
RNF12FBD475K SEI Stackpole Electronics Inc
Buy Now Datasheet
Compare Parts:
RNF12FBD475K SEI Stackpole Electronics Inc Fixed Resistor, Metal Film, 0.5W, 475000ohm, 350V, 1% +/-Tol, 100ppm/Cel, Through Hole Mount, AXIAL LEADED, ROHS COMPLIANT
Select a part to compare:
Pbfree Code Yes
Rohs Code Yes
Part Life Cycle Code Active
Ihs Manufacturer STACKPOLE ELECTRONICS INC
Package Description Axial,
Reach Compliance Code compliant
ECCN Code EAR99
HTS Code 8533.21.00.90
Factory Lead Time 22 Weeks
Samacsys Manufacturer Stackpole Electronics, Inc.
Additional Feature FLAME PROOF, PRECISION
Construction Tubular
JESD-609 Code e3
Lead Diameter 0.65 mm
Lead Length 28 mm
Mounting Feature THROUGH HOLE MOUNT
Number of Terminals 2
Operating Temperature-Max 155 °C
Operating Temperature-Min -55 °C
Package Diameter 2.75 mm
Package Length 8.75 mm
Package Shape TUBULAR PACKAGE
Package Style Axial
Packing Method BULK
Rated Power Dissipation (P) 0.5 W
Rated Temperature 70 °C
Resistance 475000 Ω
Resistor Type FIXED RESISTOR
Surface Mount NO
Technology METAL FILM
Temperature Coefficient 100 ppm/°C
Terminal Finish MATTE TIN
Terminal Shape WIRE
Tolerance 1%
Working Voltage 350 V

Alternate Parts for RNF12FBD475K

This table gives cross-reference parts and alternative options found for RNF12FBD475K. The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of RNF12FBD475K, but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.

Part Number Manufacturer Composite Price Description Compare
RNF12FTD475K SEI Stackpole Electronics Inc Check for Price Fixed Resistor, Metal Film, 0.5W, 475000ohm, 350V, 1% +/-Tol, 100ppm/Cel, Through Hole Mount, AXIAL LEADED, ROHS COMPLIANT RNF12FBD475K vs RNF12FTD475K
PRNF12FBD475K SEI Stackpole Electronics Inc Check for Price Fixed Resistor, Metal Film, 0.5W, 475000ohm, 350V, 1% +/-Tol, -100,100ppm/Cel, RNF12FBD475K vs PRNF12FBD475K
RN60D4753F SEI Stackpole Electronics Inc Check for Price Fixed Resistor, Metal Film, 0.5W, 475000ohm, 350V, 1% +/-Tol, -100,100ppm/Cel, RNF12FBD475K vs RN60D4753F
PRNF12FTD475K SEI Stackpole Electronics Inc Check for Price Fixed Resistor, Metal Film, 0.5W, 475000ohm, 350V, 1% +/-Tol, -100,100ppm/Cel, RNF12FBD475K vs PRNF12FTD475K
