Resistors / Thin Film Resistors / RNCS1206BKE1M00
Datasheets
RNCS1206BKE1M00 by: SEI Stackpole Electronics Inc

Fixed Resistor, Thin Film, 0.125W, 1000000ohm, 150V, 0.1% +/-Tol, 25ppm/Cel, Surface Mount, 1206, CHIP

Part Details for RNCS1206BKE1M00 by SEI Stackpole Electronics Inc

Results Overview of RNCS1206BKE1M00 by SEI Stackpole Electronics Inc

Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.

RNCS1206BKE1M00 Information

RNCS1206BKE1M00 by SEI Stackpole Electronics Inc is a Thin Film Resistor.
Thin Film Resistors are under the broader part category of Resistors.

Resistors are passive components that work by limiting electron flow in a circuit. They are available as fixed or as variable (potentionmeters). Read more about Resistors on our Resistors part category page.

Price & Stock for RNCS1206BKE1M00

Part # Distributor Description Stock Price Buy
DISTI # RNCS1206BKE1M00CT-ND
DigiKey RES 1M OHM 0.1% 1/8W 1206 Min Qty: 1 Lead time: 13 Weeks Container: Cut Tape (CT), Digi-Reel®, Tape & Reel (TR) 4250
In Stock
  • 1 $0.1900
  • 10 $0.1570
  • 50 $0.1394
  • 100 $0.1304
  • 500 $0.1143
  • 1,000 $0.1085
  • 2,000 $0.0888
  • 3,000 $0.0873
  • 5,000 $0.0857
  • 7,000 $0.0853
  • 10,000 $0.0850
  • 25,000 $0.0843
  • 50,000 $0.0838
  • 100,000 $0.0833
$0.0833 / $0.1900 Buy Now
DISTI # RNCS1206BKE1M00
Avnet Americas - Tape and Reel (Alt: RNCS1206BKE1M00) RoHS: Compliant Min Qty: 1000 Package Multiple: 1000 Lead time: 13 Weeks, 0 Days Container: Reel 8000 Factory Stock
  • 1,000 $0.1118
  • 2,000 $0.1100
  • 4,000 $0.1082
  • 6,000 $0.1065
  • 8,000 $0.1047
$0.1047 / $0.1118 Buy Now
DISTI # 708-RNCS1206BKE1M00
Mouser Electronics Thin Film Resistors - SMD 1MOhms 1206 0.125W 25ppm 0.1% Moist Resist AEC-Q200 RoHS: Compliant 0
  • 1 $0.2900
  • 10 $0.2060
  • 50 $0.1680
  • 100 $0.1510
  • 500 $0.1150
  • 1,000 $0.1080
  • 2,000 $0.0830
  • 5,000 $0.0810
$0.0810 / $0.2900 Order Now
DISTI # V72:2272_06972513
Arrow Electronics Res Thin Film 1206 1M Ohm 0.1% 0.125W(1/8W) ±25ppm/°C Pad SMD T/R Automotive AEC-Q200 RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 13 Weeks Date Code: 2117 Container: Cut Strips Americas - 10
  • 1 $0.1757
  • 10 $0.1740
$0.1740 / $0.1757 Buy Now
Onlinecomponents.com Res Thin Film 1206 1M Ohm 0.1% 1/8W ±25ppm/°C Molded SMD SMD Paper T/R RoHS: Compliant 3000 In Stock
8000 Factory Stock
  • 1,000 $0.1300
  • 2,000 $0.1230
  • 4,000 $0.1170
  • 10,000 $0.1110
$0.1110 / $0.1300 Buy Now
DISTI # 27185189
Verical Res Thin Film 1206 1M Ohm 0.1% 0.125W(1/8W) ±25ppm/°C Pad SMD T/R Automotive AEC-Q200 RoHS: Compliant Min Qty: 1000 Package Multiple: 1000 Americas - 13000
  • 1,000 $0.5009
  • 6,000 $0.4577
  • 9,000 $0.4258
  • 12,000 $0.4016
$0.4016 / $0.5009 Buy Now
DISTI # 69275851
Verical Res Thin Film 1206 1M Ohm 0.1% 0.125W(1/8W) ±25ppm/°C Pad SMD T/R Automotive AEC-Q200 RoHS: Compliant Min Qty: 1000 Package Multiple: 1000 Date Code: 2313 Americas - 3000
  • 1,000 $0.1690
  • 2,000 $0.1599
  • 4,000 $0.1521
  • 10,000 $0.1443
$0.1443 / $0.1690 Buy Now
NAC RESISTOR PRECISION, 1 Mohm, 1206, 0.1%, 25 ppm, 0.125W - Thin Film - Moisture Resistant RoHS: Compliant Min Qty: 1 Package Multiple: 1000 13000
  • 1 $0.2930
  • 5,000 $0.2510
  • 25,000 $0.2200
$0.2200 / $0.2930 Buy Now
Master Electronics Res Thin Film 1206 1M Ohm 0.1% 1/8W ±25ppm/°C Molded SMD SMD Paper T/R RoHS: Compliant 3000 In Stock
8000 Factory Stock
  • 1,000 $0.1300
  • 2,000 $0.1230
  • 4,000 $0.1170
  • 10,000 $0.1110
$0.1110 / $0.1300 Buy Now

Part Details for RNCS1206BKE1M00

RNCS1206BKE1M00 CAD Models

  • Part Symbol

    Part Symbol

  • Footprint

    footprint

  • 3D Model

    3D Model

Available Download Formats

Sign in to download CAD models Register or Sign In

By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy

RNCS1206BKE1M00 Part Data Attributes

Parametric Data
RNCS1206BKE1M00 SEI Stackpole Electronics Inc
Buy Now Datasheet
Compare Parts:
RNCS1206BKE1M00 SEI Stackpole Electronics Inc Fixed Resistor, Thin Film, 0.125W, 1000000ohm, 150V, 0.1% +/-Tol, 25ppm/Cel, Surface Mount, 1206, CHIP
Select a part to compare:
Pbfree Code Yes
Rohs Code Yes
Part Life Cycle Code Active
Ihs Manufacturer STACKPOLE ELECTRONICS INC
Package Description CHIP
Reach Compliance Code compliant
ECCN Code EAR99
HTS Code 8533.21.00.30
Factory Lead Time 13 Weeks
Samacsys Manufacturer Stackpole Electronics, Inc.
Additional Feature HIGH PRECISION
Construction Rectangular
JESD-609 Code e3
Mounting Feature SURFACE MOUNT
Number of Terminals 2
Operating Temperature-Max 155 °C
Operating Temperature-Min -55 °C
Package Height 0.55 mm
Package Length 3.05 mm
Package Shape RECTANGULAR PACKAGE
Package Style SMT
Package Width 1.55 mm
Packing Method TR, Paper, 7 Inch
Rated Power Dissipation (P) 0.125 W
Rated Temperature 70 °C
Reference Standard AEC-Q200
Resistance 1000000 Ω
Resistor Type FIXED RESISTOR
Size Code 1206
Surface Mount YES
Technology THIN FILM
Temperature Coefficient 25 ppm/°C
Terminal Finish Matte Tin (Sn) - with Nickel (Ni) barrier
Terminal Shape WRAPAROUND
Tolerance 0.1%
Working Voltage 150 V

RNCS1206BKE1M00 Related Parts

RNCS1206BKE1M00 Frequently Asked Questions (FAQ)

  • The recommended soldering temperature is 260°C for 10 seconds, with a peak temperature of 240°C.

  • Yes, the RNCS1206BKE1M00 is suitable for high-frequency applications up to 1 GHz due to its low inductance and high-frequency stability.

  • The power rating of the RNCS1206BKE1M00 at 70°C is 0.125W.

  • Yes, the RNCS1206BKE1M00 is AEC-Q200 qualified, making it suitable for automotive applications.

  • The MSL of the RNCS1206BKE1M00 is 1, indicating that it can withstand exposure to moisture for up to 30 days.
