Resistors / Metal Glaze/Thick Film Resistors / RMCS2512FT866R
Datasheets
RMCS2512FT866R by: SEI Stackpole Electronics Inc

Fixed Resistor, Metal Glaze/thick Film, 1W, 866ohm, 250V, 1% +/-Tol, 100ppm/Cel, Surface Mount, 2512, CHIP, ROHS COMPLIANT

Part Details for RMCS2512FT866R by SEI Stackpole Electronics Inc

Results Overview of RMCS2512FT866R by SEI Stackpole Electronics Inc

Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.

RMCS2512FT866R Information

RMCS2512FT866R by SEI Stackpole Electronics Inc is a Metal Glaze/Thick Film Resistor.
Metal Glaze/Thick Film Resistors are under the broader part category of Resistors.

Resistors are passive components that work by limiting electron flow in a circuit. They are available as fixed or as variable (potentionmeters). Read more about Resistors on our Resistors part category page.

Price & Stock for RMCS2512FT866R

Part # Distributor Description Stock Price Buy
DISTI # 738-RMCS2512FT866RCT-ND
DigiKey RES 866 OHM 1% 1W 2512 Min Qty: 1 Lead time: 14 Weeks Container: Cut Tape (CT), Digi-Reel®, Tape & Reel (TR) Temporarily Out of Stock
  • 1 $0.5200
  • 4,000 $0.1280
$0.1280 / $0.5200 Buy Now
DISTI # RMCS2512FT866R
Avnet Americas Resistor Anti Sulfured Thick Film 2512 866Ohm 1% 1W ?100ppm/?C Molded T/R - Tape and Reel (Alt: RMCS... 2512FT866R) more RoHS: Compliant Min Qty: 4000 Package Multiple: 4000 Lead time: 13 Weeks, 0 Days Container: Reel 0
  • 4,000 $0.0862
  • 8,000 $0.0862
  • 16,000 $0.0862
  • 24,000 $0.0862
  • 32,000 $0.0862
$0.0862 Buy Now
DISTI # 708-RMCS2512FT866R
Mouser Electronics Thick Film Resistors - SMD RES, AS, 2512, 866 ohm, 1%, 1W RoHS: Compliant 0
  • 4,000 $0.1250
  • 8,000 $0.1110
  • 24,000 $0.1090
  • 48,000 $0.1070
$0.1070 / $0.1250 Order Now
Onlinecomponents.com   RoHS: Compliant 0
  • 90 $0.2740
  • 100 $0.2600
  • 250 $0.1860
  • 500 $0.1300
  • 1,000 $0.1180
  • 4,000 $0.0970
  • 8,000 $0.0880
  • 12,000 $0.0860
$0.0860 / $0.2740 Buy Now
NAC RESISTOR, AS, 2512, 866 ohm, 1%, 1W - Thick Film - Anti-Sulfur RoHS: Compliant Min Qty: 4000 Package Multiple: 4000 0
  • 4,000 $0.2170
  • 20,000 $0.1860
  • 100,000 $0.1625
$0.1625 / $0.2170 Buy Now

Part Details for RMCS2512FT866R

RMCS2512FT866R Part Data Attributes

Parametric Data
RMCS2512FT866R SEI Stackpole Electronics Inc
Buy Now Datasheet
Compare Parts:
RMCS2512FT866R SEI Stackpole Electronics Inc Fixed Resistor, Metal Glaze/thick Film, 1W, 866ohm, 250V, 1% +/-Tol, 100ppm/Cel, Surface Mount, 2512, CHIP, ROHS COMPLIANT
Select a part to compare:
Pbfree Code Yes
Rohs Code Yes
Part Life Cycle Code Active
Ihs Manufacturer STACKPOLE ELECTRONICS INC
Package Description CHIP
Reach Compliance Code compliant
ECCN Code EAR99
HTS Code 8533.21.00.30
Factory Lead Time 13 Weeks
Samacsys Manufacturer Stackpole Electronics, Inc.
Additional Feature ANTI-SULFUR
Construction Rectangular
JESD-609 Code e3
Mounting Feature SURFACE MOUNT
Number of Terminals 2
Operating Temperature-Max 155 °C
Operating Temperature-Min -55 °C
Package Height 0.55 mm
Package Length 6.3 mm
Package Shape RECTANGULAR PACKAGE
Package Style SMT
Package Width 3.15 mm
Packing Method TR, Embossed Plastic, 7 Inch
Rated Power Dissipation (P) 1 W
Rated Temperature 70 °C
Resistance 866 Ω
Resistor Type FIXED RESISTOR
Size Code 2512
Surface Mount YES
Technology METAL GLAZE/THICK FILM
Temperature Coefficient 100 ppm/°C
Terminal Finish MATTE TIN OVER NICKEL
Terminal Shape WRAPAROUND
Tolerance 1%
Working Voltage 250 V

Alternate Parts for RMCS2512FT866R

This table gives cross-reference parts and alternative options found for RMCS2512FT866R. The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of RMCS2512FT866R, but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.

Part Number Manufacturer Composite Price Description Compare
WR25X8660FGL Walsin Technology Corporation Check for Price Fixed Resistor, Metal Glaze/thick Film, 1W, 866ohm, 250V, 1% +/-Tol, 100ppm/Cel, Surface Mount, 2512, CHIP RMCS2512FT866R vs WR25X8660FGL
MC2512-8660-FTW RCD Components Inc Check for Price Fixed Resistor, Metal Glaze/thick Film, 1W, 866ohm, 250V, 1% +/-Tol, 100ppm/Cel, Surface Mount, 2512, CHIP RMCS2512FT866R vs MC2512-8660-FTW
NRC-AS100F8660TRF NIC Components Corp Check for Price Fixed Resistor, Metal Glaze/thick Film, 1W, 866ohm, 250V, 1% +/-Tol, 100ppm/Cel, Surface Mount, 2512, RMCS2512FT866R vs NRC-AS100F8660TRF
NRC-AS100F8660TRQYF NIC Components Corp Check for Price Fixed Resistor, Metal Glaze/thick Film, 1W, 866ohm, 250V, 1% +/-Tol, 100ppm/Cel, Surface Mount, 2512, RMCS2512FT866R vs NRC-AS100F8660TRQYF
RM25F8660CT Cal-Chip Electronics Check for Price Fixed Resistor, Metal Glaze/thick Film, 1W, 866ohm, 200V, 1% +/-Tol, 100ppm/Cel, Surface Mount, 2512, CHIP, ROHS COMPLIANT RMCS2512FT866R vs RM25F8660CT
MC2512-8660-FBQ RCD Components Inc Check for Price Fixed Resistor, Metal Glaze/thick Film, 1W, 866ohm, 250V, 1% +/-Tol, 100ppm/Cel, Surface Mount, 2512, CHIP RMCS2512FT866R vs MC2512-8660-FBQ
NMCT2512FT866R SEI Stackpole Electronics Inc Check for Price RESISTOR, 1W, 1%, 100ppm, 866ohm, SURFACE MOUNT, 2512, CHIP, ROHS COMPLIANT RMCS2512FT866R vs NMCT2512FT866R
MC2512-8660-FT101W RCD Components Inc Check for Price Fixed Resistor, Metal Glaze/thick Film, 1W, 866ohm, 250V, 1% +/-Tol, 100ppm/Cel, Surface Mount, 2512, CHIP, ROHS COMPLIANT RMCS2512FT866R vs MC2512-8660-FT101W
MC2512-8660-FT101Q RCD Components Inc Check for Price Fixed Resistor, Metal Glaze/thick Film, 1W, 866ohm, 250V, 1% +/-Tol, 100ppm/Cel, Surface Mount, 2512, CHIP RMCS2512FT866R vs MC2512-8660-FT101Q
MC2512-8660-FBW RCD Components Inc Check for Price Fixed Resistor, Metal Glaze/thick Film, 1W, 866ohm, 250V, 1% +/-Tol, 100ppm/Cel, Surface Mount, 2512, CHIP RMCS2512FT866R vs MC2512-8660-FBW
