Resistors / Metal Glaze/Thick Film Resistors / RMCP0201FT33R2
Datasheets
RMCP0201FT33R2 by: SEI Stackpole Electronics Inc

Fixed Resistor, Metal Glaze/thick Film, 0.063W, 33.2ohm, 25V, 1% +/-Tol, 200ppm/Cel, Surface Mount, 0201, CHIP

Part Details for RMCP0201FT33R2 by SEI Stackpole Electronics Inc

Results Overview of RMCP0201FT33R2 by SEI Stackpole Electronics Inc

Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.

RMCP0201FT33R2 Information

RMCP0201FT33R2 by SEI Stackpole Electronics Inc is a Metal Glaze/Thick Film Resistor.
Metal Glaze/Thick Film Resistors are under the broader part category of Resistors.

Resistors are passive components that work by limiting electron flow in a circuit. They are available as fixed or as variable (potentionmeters). Read more about Resistors on our Resistors part category page.

Price & Stock for RMCP0201FT33R2

Part # Distributor Description Stock Price Buy
DISTI # RMCP0201FT33R2-ND
DigiKey RES 33.2 OHM 1% 1/16W 0201 Min Qty: 10000 Lead time: 17 Weeks Container: Tape & Reel (TR) Temporarily Out of Stock
  • 10,000 $0.0072
$0.0072 Buy Now
DISTI # RMCP0201FT33R2
Avnet Americas - Tape and Reel (Alt: RMCP0201FT33R2) RoHS: Compliant Min Qty: 10000 Package Multiple: 10000 Lead time: 17 Weeks, 0 Days Container: Reel 0
  • 10,000 $0.0049
  • 20,000 $0.0049
  • 40,000 $0.0049
  • 60,000 $0.0049
  • 80,000 $0.0049
$0.0049 Buy Now
DISTI # 708-RMCP0201FT33R2
Mouser Electronics Thick Film Resistors - SMD RES, 0201, 33.2 ohm, 1%, 0.063W RoHS: Compliant 0
  • 10,000 $0.0060
  • 50,000 $0.0050
$0.0050 / $0.0060 Order Now
Onlinecomponents.com   RoHS: Compliant 0
  • 10,000 $0.0050
  • 20,000 $0.0047
  • 40,000 $0.0044
  • 80,000 $0.0043
$0.0043 / $0.0050 Buy Now
NAC RESISTOR, 0201, 33.2 ohm, 1%, 0.063W - Thick Film - High Power RoHS: Compliant Min Qty: 10000 Package Multiple: 10000 0
  • 10,000 $0.0120
  • 250,000 $0.0100
$0.0100 / $0.0120 Buy Now

Part Details for RMCP0201FT33R2

RMCP0201FT33R2 Part Data Attributes

Parametric Data
RMCP0201FT33R2 SEI Stackpole Electronics Inc
Buy Now Datasheet
Compare Parts:
RMCP0201FT33R2 SEI Stackpole Electronics Inc Fixed Resistor, Metal Glaze/thick Film, 0.063W, 33.2ohm, 25V, 1% +/-Tol, 200ppm/Cel, Surface Mount, 0201, CHIP
Select a part to compare:
Rohs Code Yes
Part Life Cycle Code Active
Ihs Manufacturer STACKPOLE ELECTRONICS INC
Package Description CHIP
Reach Compliance Code compliant
Factory Lead Time 17 Weeks
Samacsys Manufacturer Stackpole Electronics, Inc.
Construction Rectangular
JESD-609 Code e3
Mounting Feature SURFACE MOUNT
Number of Terminals 2
Operating Temperature-Max 155 °C
Operating Temperature-Min -55 °C
Package Height 0.23 mm
Package Length 0.6 mm
Package Style SMT
Package Width 0.3 mm
Packing Method TR, PAPER, 7 INCH
Rated Power Dissipation (P) 0.063 W
Rated Temperature 70 °C
Resistance 33.2 Ω
Resistor Type FIXED RESISTOR
Size Code 0201
Surface Mount YES
Technology METAL GLAZE/THICK FILM
Temperature Coefficient 200 ppm/°C
Terminal Finish MATTE TIN OVER NICKEL
Terminal Shape WRAPAROUND
Tolerance 1%
Working Voltage 25 V

Alternate Parts for RMCP0201FT33R2

This table gives cross-reference parts and alternative options found for RMCP0201FT33R2. The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of RMCP0201FT33R2, but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.

Part Number Manufacturer Composite Price Description Compare
RMCF0201FT33R2 SEI Stackpole Electronics Inc Check for Price Fixed Resistor, Metal Glaze/thick Film, 0.05W, 33.2ohm, 25V, 1% +/-Tol, 200ppm/Cel, Surface Mount, 0201, CHIP RMCP0201FT33R2 vs RMCF0201FT33R2
WCR0201-33R2FI TT Electronics Welwyn Components Check for Price RESISTOR, 0.05W, 1%, 200ppm, 33.2ohm, SURFACE MOUNT, 0201, CHIP RMCP0201FT33R2 vs WCR0201-33R2FI
RMCS0201FG33R2-HP SEI Stackpole Electronics Inc Check for Price Fixed Resistor, Metal Glaze/thick Film, 0.083W, 33.2ohm, 25V, 1% +/-Tol, 200ppm/Cel, Surface Mount, 0201, CHIP RMCP0201FT33R2 vs RMCS0201FG33R2-HP
RMC1/20-33R2FB Kamaya Inc Check for Price Fixed Resistor, Metal Glaze/thick Film, 0.05W, 33.2ohm, 25V, 1% +/-Tol, 300ppm/Cel, Surface Mount, 0201, CHIP, ROHS COMPLIANT RMCP0201FT33R2 vs RMC1/20-33R2FB
CR0201F33R2P10 Ever Ohms Technology Co Ltd Check for Price Fixed Resistor, Metal Glaze/thick Film, 0.05W, 33.2ohm, 25V, 1% +/-Tol, -200,200ppm/Cel, 0201, RMCP0201FT33R2 vs CR0201F33R2P10
0201WMF332JTCE Royal Electronic Factory (Thailand) Co Ltd Check for Price Fixed Resistor, Metal Glaze/thick Film, 0.05W, 33.2ohm, 25V, 1% +/-Tol, 200ppm/Cel, Surface Mount, 0201, CHIP RMCP0201FT33R2 vs 0201WMF332JTCE
WR02X33R2FTL Walsin Technology Corporation Check for Price Fixed Resistor, Metal Glaze/thick Film, 0.05W, 33.2ohm, 25V, 1% +/-Tol, 300ppm/Cel, Surface Mount, 0201, CHIP, LEAD FREE RMCP0201FT33R2 vs WR02X33R2FTL
RMC1/20-33R2FPA Kamaya Inc Check for Price Fixed Resistor, Metal Glaze/thick Film, 0.05W, 33.2ohm, 25V, 1% +/-Tol, 300ppm/Cel, Surface Mount, 0201, CHIP, ROHS COMPLIANT RMCP0201FT33R2 vs RMC1/20-33R2FPA
WCR0201-33R2FI TT Electronics Resistors Check for Price Fixed Resistor, 0.05W, 33.2ohm, 25V, 1% +/-Tol, 200ppm/Cel, Surface Mount, 0201, CHIP RMCP0201FT33R2 vs WCR0201-33R2FI
CR0201F33R2D50 Ever Ohms Technology Co Ltd Check for Price Fixed Resistor, Metal Glaze/thick Film, 0.05W, 33.2ohm, 25V, 1% +/-Tol, -200,200ppm/Cel, 0201, RMCP0201FT33R2 vs CR0201F33R2D50
