Power Rectifier, Standard Recovery, 1 A, 400 V, SMA, 5000-REEL

Part Details for MRA4004T3G by onsemi

Results Overview of MRA4004T3G by onsemi

Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.

Applications Consumer Electronics Energy and Power Systems Transportation and Logistics Renewable Energy Automotive

MRA4004T3G Information

MRA4004T3G by onsemi is a Rectifier Diode.
Rectifier Diodes are under the broader part category of Diodes.

A diode is a electrical part that can control the direction in which the current flows in a device. Consider factors like voltage drop, current capacity, reverse voltage, and operating frequency when selecting a diode. Read more about Diodes on our Diodes part category page.
