MIC842LYC5-TR Information
MIC842LYC5-TR by Microchip Technology Inc is a Comparator.
Comparators are under the broader part category of Amplifier Circuits.
Amplifier circuits use external power to increase the amplitude of an input signal. They can be used to perform linear amplifications or logarithmic functions. Read more about Amplifier Circuits on our Amplifier Circuits part category page.
Price & Stock for MIC842LYC5-TR
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
81Y3688
|
Newark | Comparator, 1.24Vref, Push Pull, 5Sc70, Comparator Type:Precision Voltage, No. Of Comparators:1 Co... more RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 1 Container: Cut Tape | 1338 |
|
$0.6050 / $0.7700 | Buy Now |
|
DISTI #
71Y3186
|
Newark | 1.5Ua Undervoltage Comparator W/ 1.25% 1.24V Reference, 20Mv Hysteresis, Active- 5 Sc70 - T/R Rohs C... more RoHS: Compliant Min Qty: 3000 Package Multiple: 1 Date Code: 0 Container: Reel | 0 |
|
$0.6050 | Buy Now |
|
DISTI #
576-2927-1-ND
|
DigiKey | IC COMPARATOR 1 W/VOLT REF SC70 Min Qty: 1 Lead time: 22 Weeks Container: Digi-Reel®, Cut Tape (CT), Tape & Reel (TR) |
5568 In Stock |
|
$0.5700 / $0.7700 | Buy Now |
|
DISTI #
MIC842LYC5-TR
|
Avnet Americas | Analogue Comparator, Precision Voltage, 1 Channels, 12 ?s, 1.5V to 5.5V, SC-70, 5 Pins - Tape and Re... more RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Lead time: 22 Weeks, 0 Days Container: Reel | 0 |
|
$0.5733 / $0.6125 | Buy Now |
|
DISTI #
998-MIC842LYC5TR
|
Mouser Electronics | Analog Comparators 1.5uA Undervoltage Comparator w/ 1.25% 1.24V Reference, 20mV Hysteresis, Active- RoHS: Compliant | 2802 |
|
$0.5700 / $0.7700 | Buy Now |
|
DISTI #
VBF:5286_07851326
|
Arrow Electronics | Comparator Single 5.5V 5-Pin SC-70 T/R RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Lead time: 22 Weeks Date Code: 2318 | Americas - 27000 |
|
$0.6139 | Buy Now |
|
DISTI #
V72:2272_07851326
|
Arrow Electronics | Comparator Single 5.5V 5-Pin SC-70 T/R RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 22 Weeks Date Code: 1947 Container: Cut Strips | Americas - 2668 |
|
$0.6284 / $0.6799 | Buy Now |
|
DISTI #
MIC842LYC5-TR
|
Microchip Technology Inc | 1.5uA Undervoltage Comparator w/ 1.25% 1.24V Reference, 20mV Hysteresis, Active-, SC70, Projected EO... more COO: Thailand ECCN: EAR99 RoHS: Compliant Lead time: 22 Weeks, 0 Days Container: Reel |
0 Alternates Available |
|
$0.5500 / $0.7700 | Buy Now |
|
|
Onlinecomponents.com | Comparator Single 5.5V 5-Pin SC-70 T/R RoHS: Compliant |
4190 In Stock |
|
$0.5450 / $0.5590 | Buy Now |
|
DISTI #
51581573
|
Verical | Comparator Single 5.5V 5-Pin SC-70 T/R RoHS: Compliant Min Qty: 500 Package Multiple: 500 Date Code: 1830 | Americas - 4000 |
|
$0.7124 / $0.7267 | Buy Now |
Part Details for MIC842LYC5-TR
MIC842LYC5-TR CAD Models
MIC842LYC5-TR Part Data Attributes
|
|
MIC842LYC5-TR
Microchip Technology Inc
Buy Now
Datasheet
|
Compare Parts:
MIC842LYC5-TR
Microchip Technology Inc
COMPARATOR, 12000ns RESPONSE TIME, PDSO5
Select a part to compare: |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | MICROCHIP TECHNOLOGY INC | |
| Package Description | SC-70, 5 PIN | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.39.00.01 | |
| Factory Lead Time | 22 Weeks | |
| Samacsys Manufacturer | Microchip | |
| Amplifier Type | COMPARATOR | |
| JESD-30 Code | R-PDSO-G5 | |
| JESD-609 Code | e4 | |
| Length | 2.02 mm | |
| Moisture Sensitivity Level | 1 | |
| Number of Functions | 1 | |
| Number of Terminals | 5 | |
| Operating Temperature-Max | 85 °C | |
| Operating Temperature-Min | -40 °C | |
| Output Type | PUSH-PULL | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | TSSOP | |
| Package Equivalence Code | TSSOP5/6,.08 | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE, THIN PROFILE, SHRINK PITCH | |
| Packing Method | TR | |
| Peak Reflow Temperature (Cel) | 260 | |
| Qualification Status | Not Qualified | |
| Response Time-Nom | 12000 ns | |
| Screening Level | TS 16949 | |
| Seated Height-Max | 1.1 mm | |
| Supply Current-Max | 0.003 mA | |
| Supply Voltage Limit-Max | 7 V | |
| Supply Voltage-Nom (Vsup) | 1.5 V | |
| Surface Mount | YES | |
| Technology | CMOS | |
| Temperature Grade | INDUSTRIAL | |
| Terminal Finish | Nickel/Palladium/Gold (Ni/Pd/Au) | |
| Terminal Form | GULL WING | |
| Terminal Pitch | 0.65 mm | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | 40 | |
| Width | 1.25 mm |
