MCWR04X5602FTL by: SPC Multicomp

Fixed Resistor, Metal Glaze/thick Film, 0.0625W, 56000ohm, 50V, 1% +/-Tol, 100ppm/Cel, Surface Mount, 0402, CHIP

Part Details for MCWR04X5602FTL by SPC Multicomp

Results Overview of MCWR04X5602FTL by SPC Multicomp

Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.

Applications Internet of Things (IoT) Environmental Monitoring Financial Technology (Fintech) Smart Cities Transportation and Logistics Agriculture Technology Telecommunications Virtual Reality (VR), Augmented Reality (AR), and Vision Systems Education and Research Consumer Electronics Security and Surveillance Audio and Video Systems Computing and Data Storage Healthcare Entertainment and Gaming

MCWR04X5602FTL Information

MCWR04X5602FTL by SPC Multicomp is a Metal Glaze/Thick Film Resistor.
Metal Glaze/Thick Film Resistors are under the broader part category of Resistors.

Resistors are passive components that work by limiting electron flow in a circuit. They are available as fixed or as variable (potentionmeters). Read more about Resistors on our Resistors part category page.

Price & Stock for MCWR04X5602FTL

Part # Distributor Description Stock Price Buy
DISTI # 94X1287
Newark Surface Mount Chip Resistor, Thick Film, Mcwr Series, 56 Kohm, 62.5 Mw, 1%, 50 V Rohs Compliant: Yes... |Multicomp Pro MCWR04X5602FTL more RoHS: Compliant Min Qty: 10 Package Multiple: 1 Date Code: 0 Container: Cut Tape 42792
  • 10 $0.0240
  • 100 $0.0190
  • 1,000 $0.0140
$0.0140 / $0.0240 Buy Now
DISTI # 94X1288
Newark Surface Mount Chip Resistor, Thick Film, Mcwr Series, 56 Kohm, 62.5 Mw, 1%, 50 V Rohs Compliant: Yes... |Multicomp Pro MCWR04X5602FTL more RoHS: Compliant Min Qty: 10000 Package Multiple: 1 Date Code: 1 Container: Reel 20000
  • 10,000 $0.0050
  • 20,000 $0.0040
  • 50,000 $0.0030
  • 100,000 $0.0020
$0.0020 / $0.0050 Buy Now

Part Details for MCWR04X5602FTL

MCWR04X5602FTL CAD Models

  • Part Symbol

    Part Symbol

  • Footprint

    footprint

  • 3D Model

    3D Model

Available Download Formats

Sign in to download CAD models Register or Sign In

By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy

MCWR04X5602FTL Part Data Attributes

Parametric Data
MCWR04X5602FTL SPC Multicomp
Buy Now Datasheet
Compare Parts:
MCWR04X5602FTL SPC Multicomp Fixed Resistor, Metal Glaze/thick Film, 0.0625W, 56000ohm, 50V, 1% +/-Tol, 100ppm/Cel, Surface Mount, 0402, CHIP
Select a part to compare:
Rohs Code Yes
Part Life Cycle Code Active
Ihs Manufacturer MULTICOMP PRO
Package Description CHIP
Reach Compliance Code unknown
Samacsys Manufacturer Multicomp Pro
Additional Feature LASER TRIMMABLE, RATED AC VOLTAGE (V): 50
Construction Chip
Mounting Feature SURFACE MOUNT
Number of Terminals 2
Operating Temperature-Max 155 °C
Operating Temperature-Min -55 °C
Package Height 0.35 mm
Package Length 1 mm
Package Style SMT
Package Width 0.5 mm
Packing Method TR, Paper, 7 Inch
Rated Power Dissipation (P) 0.0625 W
Rated Temperature 70 °C
Resistance 56000 Ω
Resistor Type FIXED RESISTOR
Size Code 0402
Surface Mount YES
Technology METAL GLAZE/THICK FILM
Temperature Coefficient 100 ppm/°C
Terminal Shape WRAPAROUND
Tolerance 1%
Working Voltage 50 V
