MAX5223EKA+T Information
MAX5223EKA+T by Analog Devices Inc is a Digital to Analog Converter.
Digital to Analog Converters are under the broader part category of Converters.
A converter is an electrical circuit that transforms electric energy into a different form that will support a elecrical load needed by a device. Read more about Converters on our Converters part category page.
Price & Stock for MAX5223EKA+T
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
700-MAX5223EKAT
|
Mouser Electronics | Digital to Analog Converters - DAC Low-Power, Dual, 8-Bit, Voltage-Output S RoHS: Compliant | 2495 |
|
$2.4500 / $4.8100 | Buy Now |
|
|
Analog Devices Inc | Low-Power, Dual, 8-Bit, Voltag Min Qty: 1 Package Multiple: 1 | 9035 |
|
$2.4500 / $6.3100 | Buy Now |
Part Details for MAX5223EKA+T
MAX5223EKA+T CAD Models
MAX5223EKA+T Part Data Attributes
|
|
MAX5223EKA+T
Analog Devices Inc
Buy Now
Datasheet
|
Compare Parts:
MAX5223EKA+T
Analog Devices Inc
Low-Power, Dual, 8-Bit, Voltage-Output Serial DAC in 8-Pin SOT23, 8-SOT_23-N/A, 8 Pins, -40 to 85C
Select a part to compare: |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | ANALOG DEVICES INC | |
| Part Package Code | 8-SOT_23-N/A | |
| Package Description | 3 X 3 MM, SOT-23, 8 PIN | |
| Pin Count | 8 | |
| Manufacturer Package Code | 8-SOT_23-N/A | |
| Reach Compliance Code | compliant | |
| Date Of Intro | 2001-02-23 | |
| Samacsys Manufacturer | Analog Devices | |
| Analog Output Voltage-Max | 3.6 V | |
| Analog Output Voltage-Min | ||
| Converter Type | D/A CONVERTER | |
| Input Bit Code | BINARY | |
| Input Format | SERIAL | |
| JESD-30 Code | R-PDSO-G8 | |
| JESD-609 Code | e3 | |
| Length | 2.9 mm | |
| Linearity Error-Max (EL) | 0.3906% | |
| Moisture Sensitivity Level | 1 | |
| Number of Bits | 8 | |
| Number of Functions | 1 | |
| Number of Terminals | 8 | |
| Operating Temperature-Max | 85 °C | |
| Operating Temperature-Min | -40 °C | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | LSSOP | |
| Package Equivalence Code | TSSOP8,.1 | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE, LOW PROFILE, SHRINK PITCH | |
| Peak Reflow Temperature (Cel) | 260 | |
| Qualification Status | Not Qualified | |
| Seated Height-Max | 1.45 mm | |
| Settling Time-Nom (tstl) | 50 µs | |
| Supply Current-Max | 0.275 mA | |
| Supply Voltage-Nom | 3.6 V | |
| Surface Mount | YES | |
| Technology | BICMOS | |
| Temperature Grade | INDUSTRIAL | |
| Terminal Finish | Matte Tin (Sn) | |
| Terminal Form | GULL WING | |
| Terminal Pitch | 0.65 mm | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Width | 1.625 mm |
