MAX4212EUK+T Information
MAX4212EUK+T by Analog Devices Inc is an Operational Amplifier.
Operational Amplifiers are under the broader part category of Amplifier Circuits.
Amplifier circuits use external power to increase the amplitude of an input signal. They can be used to perform linear amplifications or logarithmic functions. Read more about Amplifier Circuits on our Amplifier Circuits part category page.
Price & Stock for MAX4212EUK+T
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
700-MAX4212EUKT
|
Mouser Electronics | High Speed Operational Amplifiers Miniature, 300MHz, Single-Supply, Rail-t RoHS: Compliant | 5336 |
|
$5.2700 / $9.8100 | Buy Now |
|
|
Analog Devices Inc | Miniature, 300MHz, Single-Supp Min Qty: 1 Package Multiple: 1 | 83 |
|
$4.3200 / $11.3100 | Buy Now |
Part Details for MAX4212EUK+T
MAX4212EUK+T CAD Models
MAX4212EUK+T Part Data Attributes
|
|
MAX4212EUK+T
Analog Devices Inc
Buy Now
Datasheet
|
Compare Parts:
MAX4212EUK+T
Analog Devices Inc
Miniature, 300MHz, Single-Supply, Rail-to-Rail Op Amps with Enable, 5-SOT_23-N/A, 5 Pins, -40 to 85C
Select a part to compare: |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | ANALOG DEVICES INC | |
| Part Package Code | 5-SOT_23-N/A | |
| Package Description | MO-178-AA, SOT-23, 5 PIN | |
| Pin Count | 5 | |
| Manufacturer Package Code | 5-SOT_23-N/A | |
| Reach Compliance Code | compliant | |
| Date Of Intro | 1997-01-07 | |
| Samacsys Manufacturer | Analog Devices | |
| Amplifier Type | OPERATIONAL AMPLIFIER | |
| JESD-30 Code | R-PDSO-G5 | |
| JESD-609 Code | e3 | |
| Length | 2.9 mm | |
| Moisture Sensitivity Level | 1 | |
| Number of Functions | 1 | |
| Number of Terminals | 5 | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | LSSOP | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE, LOW PROFILE, SHRINK PITCH | |
| Peak Reflow Temperature (Cel) | 260 | |
| Qualification Status | Not Qualified | |
| Seated Height-Max | 1.45 mm | |
| Surface Mount | YES | |
| Temperature Grade | INDUSTRIAL | |
| Terminal Finish | Matte Tin (Sn) | |
| Terminal Form | GULL WING | |
| Terminal Pitch | 0.95 mm | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Width | 1.625 mm |
