MAX16550AGPN+T Information
MAX16550AGPN+T by Analog Devices Inc is a Power Management Circuit.
Power Management Circuits are under the broader part category of Power Circuits.
A power circuit delivers electricity in order to operate a load for an electronic device. Power circuits include transformers, generators and switches. Read more about Power Circuits on our Power Circuits part category page.
Price & Stock for MAX16550AGPN+T
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
|
Analog Devices Inc | 30A, 10.8-13.2V Integrated Pro Min Qty: 2500 Package Multiple: 1 | 0 |
|
Buy Now | |
|
|
Rochester Electronics | MAX16550A - Integrated Protection IC on 12V Bus with an Integrated MOSFET, Lossless Current Sensing,... more RoHS: Compliant Status: Active Min Qty: 1 | 15000 |
|
$1.0500 / $1.3100 | Buy Now |
Part Details for MAX16550AGPN+T
MAX16550AGPN+T CAD Models
MAX16550AGPN+T Part Data Attributes
|
|
MAX16550AGPN+T
Analog Devices Inc
Buy Now
Datasheet
|
Compare Parts:
MAX16550AGPN+T
Analog Devices Inc
Integrated Protection IC on 12V Bus with an Integrated MOSFET, Lossless Current Sensing, and PMBus Interface, 18-LFCSP-4X4.5X0.95, 18 Pins, 0 to 125C
Select a part to compare: |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | ANALOG DEVICES INC | |
| Part Package Code | 18-LFCSP-4X4.5X0.95 | |
| Package Description | FCQFN-18 | |
| Pin Count | 18 | |
| Manufacturer Package Code | 18-LFCSP-4X4.5X0.95 | |
| Reach Compliance Code | compliant | |
| Date Of Intro | 2021-03-31 | |
| Samacsys Manufacturer | Analog Devices | |
| Adjustable Threshold | YES | |
| Analog IC - Other Type | POWER SUPPLY SUPPORT CIRCUIT | |
| JESD-30 Code | R-XXSS-N18 | |
| JESD-609 Code | e3 | |
| Length | 4.5 mm | |
| Moisture Sensitivity Level | 1 | |
| Number of Channels | 1 | |
| Number of Functions | 1 | |
| Number of Terminals | 18 | |
| Operating Temperature-Max | 125 °C | |
| Operating Temperature-Min | ||
| Package Body Material | UNSPECIFIED | |
| Package Code | XSS | |
| Package Shape | RECTANGULAR | |
| Package Style | SPECIAL SHAPE | |
| Peak Reflow Temperature (Cel) | 260 | |
| Seated Height-Max | 1 mm | |
| Supply Current-Max (Isup) | 10 mA | |
| Supply Voltage-Max (Vsup) | 13.2 V | |
| Supply Voltage-Min (Vsup) | 10.8 V | |
| Supply Voltage-Nom (Vsup) | 12 V | |
| Surface Mount | YES | |
| Temperature Grade | OTHER | |
| Terminal Finish | Matte Tin (Sn) | |
| Terminal Form | NO LEAD | |
| Terminal Pitch | 0.5 mm | |
| Terminal Position | UNSPECIFIED | |
| Threshold Voltage-Nom | +1V | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Width | 4 mm |
