LT3008MPTS8#TRMPBF Information
LT3008MPTS8#TRMPBF by Analog Devices Inc is a Linear Regulator IC.
Linear Regulator ICs are under the broader part category of Power Circuits.
A power circuit delivers electricity in order to operate a load for an electronic device. Power circuits include transformers, generators and switches. Read more about Power Circuits on our Power Circuits part category page.
Price & Stock for LT3008MPTS8#TRMPBF
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
50AK5192
|
Newark | Ldo, Adj, 0.02A, Tsot-23, -55 To 125Degc, Output Type:Adjustable, Input Voltage Min:2V, Input Vol... more RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 1 Container: Cut Tape | 572 |
|
$5.7800 / $11.6600 | Buy Now |
|
DISTI #
LT3008MPTS8#TRMPBFCT-ND
|
DigiKey | IC REG LIN POS ADJ 20MA TSOT23-8 Min Qty: 1 Lead time: 10 Weeks Container: Cut Tape (CT), Digi-Reel®, Tape & Reel (TR) |
1457 In Stock |
|
$6.0916 / $10.1800 | Buy Now |
|
DISTI #
584-3008MPTS8TRMPBF
|
Mouser Electronics | LDO Voltage Regulators 3uA IQ, 20mA, 45V L Drop Lin Regs RoHS: Compliant | 370 |
|
$5.6200 / $11.3500 | Buy Now |
|
DISTI #
E22:3490_01038010
|
Arrow Electronics | LDO Regulator Pos 0.6V to 44.5V 0.02A 8-Pin TSOT-23 T/R RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 10 Weeks Date Code: 2329 | Europe - 485 |
|
$5.1720 / $5.8430 | Buy Now |
|
|
Analog Devices Inc | 3µA IQ, 20mA, 45V L Drop Lin R Package Multiple: 500 | 4792 |
|
$4.5000 / $11.6600 | Buy Now |
|
DISTI #
35212223
|
Verical | LDO Regulator Pos 0.6V to 44.5V 0.02A 8-Pin TSOT-23 T/R RoHS: Compliant Min Qty: 500 Package Multiple: 500 | Americas - 4500 |
|
$5.4000 | Buy Now |
|
DISTI #
LT3008MPTS8TRMP
|
Richardson RFPD | VOLTAGE REGULATOR RoHS: Compliant Min Qty: 500 | 0 |
|
$5.8100 / $6.2000 | Buy Now |
Part Details for LT3008MPTS8#TRMPBF
LT3008MPTS8#TRMPBF CAD Models
LT3008MPTS8#TRMPBF Part Data Attributes
|
|
LT3008MPTS8#TRMPBF
Analog Devices Inc
Buy Now
Datasheet
|
Compare Parts:
LT3008MPTS8#TRMPBF
Analog Devices Inc
LT3008MPTS8#TRMPBF
Select a part to compare: |
| Pbfree Code | No | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | ANALOG DEVICES INC | |
| Package Description | LEAD FREE, PLASTIC, MO-193, TSOT-23, 8 PIN | |
| Pin Count | 8 | |
| Manufacturer Package Code | 05-08-1637 | |
| Reach Compliance Code | compliant | |
| Samacsys Manufacturer | Analog Devices | |
| Dropout Voltage1-Max | 0.5 V | |
| JESD-30 Code | R-PDSO-G8 | |
| JESD-609 Code | e3 | |
| Length | 2.9 mm | |
| Moisture Sensitivity Level | 1 | |
| Number of Functions | 1 | |
| Number of Terminals | 8 | |
| Operating Temperature TJ-Max | 125 °C | |
| Operating Temperature TJ-Min | -55 °C | |
| Output Current1-Max | 0.02 A | |
| Output Voltage1-Max | 44.5 V | |
| Output Voltage1-Min | 0.6 V | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | VSSOP | |
| Package Equivalence Code | TSSOP8,.1 | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE, VERY THIN PROFILE, SHRINK PITCH | |
| Packing Method | TR | |
| Peak Reflow Temperature (Cel) | 260 | |
| Regulator Type | ADJUSTABLE POSITIVE SINGLE OUTPUT LDO REGULATOR | |
| Seated Height-Max | 1 mm | |
| Surface Mount | YES | |
| Technology | BIPOLAR | |
| Terminal Finish | Matte Tin (Sn) - annealed | |
| Terminal Form | GULL WING | |
| Terminal Pitch | 0.65 mm | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Width | 1.625 mm |
Alternate Parts for LT3008MPTS8#TRMPBF
This table gives cross-reference parts and alternative options found for LT3008MPTS8#TRMPBF. The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of LT3008MPTS8#TRMPBF, but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.
| Part Number | Manufacturer | Composite Price | Description | Compare |
|---|---|---|---|---|
| LT3008MPTS8#TRMPBF | Linear Technology | Check for Price | LT3008 Series - 3µA IQ, 20mA, 45V Low Dropout Linear Regulators; Package: SOT; Pins: 8; Temperature Range: -55°C to 125°C | LT3008MPTS8#TRMPBF vs LT3008MPTS8#TRMPBF |
| LT3008MPTS8#TRM | Linear Technology | Check for Price | LT3008 Series - 3µA IQ, 20mA, 45V Low Dropout Linear Regulators; Package: SOT; Pins: 8; Temperature Range: -55°C to 125°C | LT3008MPTS8#TRMPBF vs LT3008MPTS8#TRM |
| LT3008MPTS8#TRM | Analog Devices Inc | Check for Price | LT3008MPTS8#TRM | LT3008MPTS8#TRMPBF vs LT3008MPTS8#TRM |
LT3008MPTS8#TRMPBF Frequently Asked Questions (FAQ)
-
A 2-layer or 4-layer PCB with a solid ground plane and thermal vias under the IC is recommended. This helps to dissipate heat efficiently and reduce thermal resistance.
-
To ensure stability, use a minimum output capacitance of 10uF, and ensure that the output capacitor's ESR is less than 1 ohm. Additionally, use a low-ESR input capacitor and keep the input and output capacitors close to the IC.
-
The maximum input voltage rating is 15V, but it's recommended to operate the device within the specified input voltage range of 2.9V to 14V for optimal performance and reliability.
-
The LT3008MPTS8 is rated for operation up to 125°C, but the device's performance and reliability may degrade at high temperatures. Ensure proper thermal management and consider derating the device's output current and voltage at high temperatures.
-
