Part Details for LMZ23605TZ/NOPB by Texas Instruments
Results Overview of LMZ23605TZ/NOPB by Texas Instruments
- Distributor Offerings: (6 listings)
- Number of FFF Equivalents: (0 replacements)
- CAD Models: (Available)
- Number of Functional Equivalents: (2 options)
- Part Data Attributes: (Available)
- Reference Designs: (Not Available)
Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.
Applications
Energy and Power Systems
Transportation and Logistics
Renewable Energy
Automotive
LMZ23605TZ/NOPB Information
LMZ23605TZ/NOPB by Texas Instruments is a Switching Regulator or Controller.
Switching Regulator or Controllers are under the broader part category of Power Circuits.
A power circuit delivers electricity in order to operate a load for an electronic device. Power circuits include transformers, generators and switches. Read more about Power Circuits on our Power Circuits part category page.
Price & Stock for LMZ23605TZ/NOPB
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
LMZ23605TZ/NOPB-ND
|
DigiKey | DC DC CONVERTER 0.8-6V Min Qty: 1 Lead time: 6 Weeks Container: Tube |
461 In Stock |
|
$15.9960 / $18.5600 | Buy Now |
|
DISTI #
926-LMZ23605TZ/NOPB
|
Mouser Electronics | Switching Voltage Regulators Gen2 36Vin 5A Module A 926-LMZ23605TZE/NOPB RoHS: Compliant | 897 |
|
$15.1900 / $17.5900 | Buy Now |
|
|
Quest Components | SWITCHING REGULATOR/CONTROLLER, CURRENT-MODE, 5A, 914KHZ SWITCHING FREQ-MAX | 40 |
|
$21.6000 / $24.0000 | Buy Now |
|
DISTI #
SMC-LMZ23605TZ/NOPB
|
Sensible Micro Corporation | OEM Excess 5-7 Days Leadtime, We are an AS6081 Certified Vendor, 1 Yr Warranty RoHS: Not Compliant Min Qty: 25 Lead time: 2 Weeks, 0 Days | 48 |
|
RFQ | |
|
|
LCSC | TO-PMOD-7 DC-DC Power Modules ROHS | 9 |
|
$19.7248 / $24.1223 | Buy Now |
|
|
Win Source Electronics | LMZ23605 5A SIMPLE SWITCHER® Power Module with 36V Maximum Input Voltage | 4970 |
|
$5.8334 / $7.5347 | Buy Now |
Part Details for LMZ23605TZ/NOPB
LMZ23605TZ/NOPB CAD Models
LMZ23605TZ/NOPB Part Data Attributes
|
|
LMZ23605TZ/NOPB
Texas Instruments
Buy Now
Datasheet
|
Compare Parts:
LMZ23605TZ/NOPB
Texas Instruments
5A SIMPLE SWITCHER® Power Module with 36V Maximum Input Voltage 7-TO-PMOD -40 to 85
Select a part to compare: |
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | TEXAS INSTRUMENTS INC | |
| Part Package Code | SIP | |
| Package Description | TO-PMOD, 7 PIN | |
| Pin Count | 7 | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.39.00.01 | |
| Samacsys Manufacturer | Texas Instruments | |
| Additional Feature | ADJUSTABLE OUTPUT VOLTAGE RANGE FROM 0.8 TO 6 VOLT | |
| Analog IC - Other Type | SWITCHING REGULATOR | |
| Control Mode | CURRENT-MODE | |
| Control Technique | PULSE WIDTH MODULATION | |
| Input Voltage-Max | 36 V | |
| Input Voltage-Min | 6 V | |
| Input Voltage-Nom | 12 V | |
| JESD-30 Code | R-PSSO-G7 | |
| JESD-609 Code | e3 | |
| Length | 10.16 mm | |
| Moisture Sensitivity Level | 3 | |
| Number of Functions | 1 | |
| Number of Outputs | 1 | |
| Number of Terminals | 7 | |
| Operating Temperature-Max | 85 °C | |
| Operating Temperature-Min | -40 °C | |
| Output Current-Max | 5 A | |
| Output Voltage-Max | 6 V | |
| Output Voltage-Min | 0.8 V | |
| Output Voltage-Nom | 3.3 V | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | HSOP | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE, HEAT SINK/SLUG | |
| Peak Reflow Temperature (Cel) | 245 | |
| Seated Height-Max | 4.58 mm | |
| Surface Mount | YES | |
| Switcher Configuration | BUCK-BOOST | |
| Switching Frequency-Max | 950 kHz | |
| Temperature Grade | INDUSTRIAL | |
| Terminal Finish | Tin (Sn) | |
| Terminal Form | GULL WING | |
| Terminal Pitch | 1.27 mm | |
| Terminal Position | SINGLE | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Width | 9.85 mm |
Alternate Parts for LMZ23605TZ/NOPB
This table gives cross-reference parts and alternative options found for LMZ23605TZ/NOPB. The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of LMZ23605TZ/NOPB, but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.
| Part Number | Manufacturer | Composite Price | Description | Compare |
|---|---|---|---|---|
| LMZ23605TZX/NOPB | Texas Instruments | Check for Price | 5A SIMPLE SWITCHER® Power Module with 36V Maximum Input Voltage 7-TO-PMOD -40 to 85 | LMZ23605TZ/NOPB vs LMZ23605TZX/NOPB |
| MP4315GRE | Monolithic Power Systems | Check for Price | Switching Regulator, Current-mode, 5A, 1180kHz Switching Freq-Max, QFN-20 | LMZ23605TZ/NOPB vs MP4315GRE |
