ESD5V0D3B-TP by: Micro Commercial Components

Trans Voltage Suppressor Diode, 500W, 5V V(RWM), Unidirectional, 2 Element, Silicon, LEAD FREE, PLASTIC PACKAGE-2

Part Details for ESD5V0D3B-TP by Micro Commercial Components

Results Overview of ESD5V0D3B-TP by Micro Commercial Components

Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.

ESD5V0D3B-TP Information

ESD5V0D3B-TP by Micro Commercial Components is a Transient Suppressor.
Transient Suppressors are under the broader part category of Diodes.

A diode is a electrical part that can control the direction in which the current flows in a device. Consider factors like voltage drop, current capacity, reverse voltage, and operating frequency when selecting a diode. Read more about Diodes on our Diodes part category page.

Price & Stock for ESD5V0D3B-TP

Part # Distributor Description Stock Price Buy
DISTI # 21AM9601
Newark Esd Protect Device, 5V, Sod-323, 2Pin Rohs Compliant: Yes |Micro Commercial Components ESD5V0D3B-TP RoHS: Compliant Min Qty: 5 Package Multiple: 1 Date Code: 0 Container: Cut Tape 2960
  • 1 $0.5110
  • 10 $0.3710
  • 25 $0.3110
  • 50 $0.2520
  • 100 $0.1920
  • 250 $0.1840
  • 500 $0.1750
  • 1,000 $0.1590
$0.1590 / $0.5110 Buy Now
DISTI # ESD5V0D3B-TPMSCT-ND
DigiKey TVS DIODE 5VWM 13.5VC SOD323 Min Qty: 1 Lead time: 16 Weeks Container: Cut Tape (CT), Digi-Reel®, Tape & Reel (TR) 7187
In Stock
  • 1 $0.3800
  • 10 $0.2470
  • 100 $0.1230
  • 500 $0.1190
  • 1,000 $0.1150
  • 3,000 $0.0840
  • 6,000 $0.0790
  • 9,000 $0.0725
$0.0725 / $0.3800 Buy Now
DISTI # 833-ESD5V0D3B-TP
Mouser Electronics ESD Protection Diodes / TVS Diodes 5V, 1.0uA RoHS: Compliant 6294
  • 1 $0.3700
  • 10 $0.2470
  • 100 $0.1190
  • 500 $0.1170
  • 1,000 $0.1150
  • 3,000 $0.0790
  • 6,000 $0.0750
  • 9,000 $0.0720
$0.0720 / $0.3700 Buy Now
Bristol Electronics   950
RFQ
Quest Components TRANS VOLTAGE SUPPRESSOR DIODE, 500W, 5V V(RWM), UNIDIRECTIONAL, 2 ELEMENT, SILICON 760
  • 1 $0.5250
  • 49 $0.3150
  • 191 $0.2625
$0.2625 / $0.5250 Buy Now
Quest Components TRANS VOLTAGE SUPPRESSOR DIODE, 500W, 5V V(RWM), UNIDIRECTIONAL, 2 ELEMENT, SILICON 306
  • 1 $0.2100
  • 25 $0.1750
  • 58 $0.1400
$0.1400 / $0.2100 Buy Now
New Advantage Corporation ESD5V0D3B Series 5.8 V 500 W SMT Bi-Directional ESD Protection - SOD-323 RoHS: Compliant Min Qty: 1 Package Multiple: 3000 12000
  • 6,000 $0.0323
  • 12,000 $0.0300
$0.0300 / $0.0323 Buy Now
Vyrian Diodes 11022
RFQ

Part Details for ESD5V0D3B-TP

ESD5V0D3B-TP CAD Models

  • Part Symbol

    Part Symbol

  • Footprint

    footprint

  • 3D Model

    3D Model

Available Download Formats

Sign in to download CAD models Register or Sign In

By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy

ESD5V0D3B-TP Part Data Attributes

Parametric Data
ESD5V0D3B-TP Micro Commercial Components
Buy Now Datasheet
Compare Parts:
ESD5V0D3B-TP Micro Commercial Components Trans Voltage Suppressor Diode, 500W, 5V V(RWM), Unidirectional, 2 Element, Silicon, LEAD FREE, PLASTIC PACKAGE-2
Select a part to compare:
Pbfree Code Yes
Rohs Code Yes
Part Life Cycle Code Active
Ihs Manufacturer MICRO COMMERCIAL COMPONENTS CORP
Package Description PACKAGE-2
Pin Count 2
Reach Compliance Code compliant
ECCN Code EAR99
HTS Code 8541.10.00.50
Samacsys Manufacturer MCC
Breakdown Voltage-Min 6 V
Clamping Voltage-Max 15 V
Configuration COMMON CATHODE, 2 ELEMENTS
Diode Element Material SILICON
Diode Type TRANS VOLTAGE SUPPRESSOR DIODE
JESD-30 Code R-PDSO-G2
JESD-609 Code e3
Moisture Sensitivity Level 1
Non-rep Peak Rev Power Dis-Max 500 W
Number of Elements 2
Number of Terminals 2
Operating Temperature-Max 150 °C
Operating Temperature-Min -55 °C
Package Body Material PLASTIC/EPOXY
Package Shape RECTANGULAR
Package Style SMALL OUTLINE
Peak Reflow Temperature (Cel) 260
Polarity UNIDIRECTIONAL
Qualification Status Not Qualified
Rep Pk Reverse Voltage-Max 5 V
Surface Mount YES
Technology AVALANCHE
Terminal Finish MATTE TIN
Terminal Form GULL WING
Terminal Position DUAL
Time@Peak Reflow Temperature-Max (s) 10

ESD5V0D3B-TP Related Parts

ESD5V0D3B-TP Frequently Asked Questions (FAQ)

  • A good PCB layout for optimal ESD protection involves placing the ESD5V0D3B-TP close to the input connector, using short traces, and minimizing the distance between the device and the protected circuit. Additionally, a ground plane underneath the device can help to reduce parasitic inductance.

  • The ESD5V0D3B-TP is designed to handle high surge currents, up to 30A, for a short duration (typically 8/20μs). The device's internal structure is optimized to dissipate the surge energy quickly, protecting the downstream circuitry.

  • The ESD5V0D3B-TP is rated for operation from -40°C to 125°C, making it suitable for a wide range of applications, including automotive, industrial, and consumer electronics.

  • Yes, the ESD5V0D3B-TP is suitable for high-speed data lines, such as USB, HDMI, and Ethernet, due to its low capacitance (typically 0.4pF) and high bandwidth (>1GHz).

  • Yes, the ESD5V0D3B-TP meets the requirements of various automotive standards, including IEC 61000-4-2 and ISO 7637-3, making it suitable for use in automotive applications.
