Part Details for AVS1ACP08 by STMicroelectronics
Results Overview of AVS1ACP08 by STMicroelectronics
- Distributor Offerings: (17 listings)
- Number of FFF Equivalents: (0 replacements)
- CAD Models: (Available)
- Number of Functional Equivalents: (0 options)
- Part Data Attributes: (Available)
- Reference Designs: (Not Available)
Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.
Applications
Consumer Electronics
Security and Surveillance
Environmental Monitoring
Internet of Things (IoT)
Space Technology
Smart Cities
Aerospace and Defense
Healthcare
Agriculture Technology
Virtual Reality (VR), Augmented Reality (AR), and Vision Systems
Medical Imaging
Robotics and Drones
AVS1ACP08 Information
AVS1ACP08 by STMicroelectronics is a Switching Regulator or Controller.
Switching Regulator or Controllers are under the broader part category of Power Circuits.
A power circuit delivers electricity in order to operate a load for an electronic device. Power circuits include transformers, generators and switches. Read more about Power Circuits on our Power Circuits part category page.
Price & Stock for AVS1ACP08
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
1132005
|
Farnell | AUTO VOLT SWITCH CNTRL, 1ACP08, DIP RoHS: Compliant Min Qty: 1 Lead time: 18 Weeks, 1 Days Container: Each | 522 |
|
$2.6000 / $3.6480 | Buy Now |
|
DISTI #
497-4551-ND
|
DigiKey | IC OFF-LINE CTRLR HV 8DIP Min Qty: 1 Lead time: 35 Weeks Container: Tube |
826 In Stock |
|
$2.2639 / $4.1500 | Buy Now |
|
DISTI #
AVS1ACP08
|
Avnet Americas | Automatic Voltage Switch 8-Pin PDIP Tube - Rail/Tube (Alt: AVS1ACP08) RoHS: Compliant Min Qty: 2000 Package Multiple: 2000 Lead time: 35 Weeks, 0 Days Container: Tube | 0 |
|
$1.7586 / $1.8576 | Buy Now |
|
DISTI #
AVS1ACP08
|
Avnet Americas | Automatic Voltage Switch 8-Pin PDIP Tube - Rail/Tube (Alt: AVS1ACP08) RoHS: Compliant Min Qty: 2000 Package Multiple: 2000 Lead time: 35 Weeks, 0 Days Container: Tube | 0 |
|
$1.7586 / $1.8576 | Buy Now |
|
DISTI #
511-AVS1ACP08
|
Mouser Electronics | Triacs Auto Voltage Switch RoHS: Compliant | 9263 |
|
$2.3900 / $3.2800 | Buy Now |
|
DISTI #
V36:1790_06547713
|
Arrow Electronics | Power Switch 1-OUT 8-Pin PDIP Tube RoHS: Compliant Min Qty: 2000 Package Multiple: 2000 Lead time: 35 Weeks Date Code: 2443 | Americas - 8000 |
|
$1.7780 / $1.8650 | Buy Now |
|
|
Future Electronics | AVS12 Series 600 V 12 A Through Hole Automatic Voltage Switch - DIP-8 RoHS: Compliant pbFree: Yes Min Qty: 1 Package Multiple: 1 Lead time: 35 Weeks Container: Tube |
2144 Tube |
|
$1.8900 / $2.0400 | Buy Now |
|
DISTI #
86931771
|
Verical | Power Switch 1-OUT 8-Pin PDIP Tube RoHS: Compliant Min Qty: 2000 Package Multiple: 2000 Date Code: 2443 | Americas - 8000 |
|
$1.7780 / $1.8650 | Buy Now |
|
|
Bristol Electronics | 347 |
|
RFQ | ||
|
|
Bristol Electronics | 152 |
|
RFQ |
Part Details for AVS1ACP08
AVS1ACP08 CAD Models
AVS1ACP08 Part Data Attributes
|
|
AVS1ACP08
STMicroelectronics
Buy Now
Datasheet
|
Compare Parts:
AVS1ACP08
STMicroelectronics
0.04A SWITCHING CONTROLLER, 46kHz SWITCHING FREQ-MAX, PDIP8, PLASTIC, DIP-8
Select a part to compare: |
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | STMICROELECTRONICS | |
| Part Package Code | DIP | |
| Package Description | PLASTIC, DIP-8 | |
| Pin Count | 8 | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.39.00.01 | |
| Factory Lead Time | 35 Weeks | |
| Samacsys Manufacturer | STMicroelectronics | |
| Analog IC - Other Type | SWITCHING CONTROLLER | |
| Input Voltage-Max | -10 V | |
| Input Voltage-Min | -8 V | |
| Input Voltage-Nom | -9 V | |
| JESD-30 Code | R-PDIP-T8 | |
| JESD-609 Code | e3 | |
| Neg Supply Voltage-Nom (Vsup) | -9 V | |
| Number of Functions | 1 | |
| Number of Terminals | 8 | |
| Operating Temperature-Max | 70 °C | |
| Operating Temperature-Min | ||
| Output Current-Max | 0.04 A | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | DIP | |
| Package Equivalence Code | DIP8,.3 | |
| Package Shape | RECTANGULAR | |
| Package Style | IN-LINE | |
| Qualification Status | Not Qualified | |
| Seated Height-Max | 4.8 mm | |
| Supply Current-Max (Isup) | 30 mA | |
| Surface Mount | NO | |
| Switcher Configuration | SINGLE | |
| Switching Frequency-Max | 46 kHz | |
| Temperature Grade | COMMERCIAL | |
| Terminal Finish | MATTE TIN | |
| Terminal Form | THROUGH-HOLE | |
| Terminal Pitch | 2.54 mm | |
| Terminal Position | DUAL | |
| Width | 7.62 mm |
