3D Model
Available Download Formats
By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy
Part Details for AD8302ARU by Analog Devices Inc
Results Overview of AD8302ARU by Analog Devices Inc
- Distributor Offerings: (5 listings)
- Number of FFF Equivalents: (0 replacements)
- CAD Models: (Available)
- Number of Functional Equivalents: (5 options)
- Part Data Attributes: (Available)
- Reference Designs: (Not Available)
Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.
Applications
Environmental Monitoring
Internet of Things (IoT)
Industrial Automation
Smart Cities
Transportation and Logistics
Energy and Power Systems
Telecommunications
Automotive
Consumer Electronics
Security and Surveillance
Aerospace and Defense
Healthcare
Communication and Networking
AD8302ARU Information
AD8302ARU by Analog Devices Inc is an Other Signal Circuit.
Other Signal Circuits are under the broader part category of Signal Circuits.
A signal is an electronic means of transmitting information, either as an analog signal with continuous values or a digital signal with discrete values. Signals are used in various systems and networks. Read more about Signal Circuits on our Signal Circuits part category page.
Price & Stock for AD8302ARU
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
|
Quest Components | IC, LF-2.7 GHZ RF/IF GAIN AND PHASE DETECTOR, TSSOP-14 | 7 |
|
$60.9007 / $64.1060 | Buy Now |
|
|
Rochester Electronics | RF Amplifier, IF Gain and Phase Detector RoHS: Not Compliant Status: Obsolete Min Qty: 1 | 18221 |
|
$16.0200 / $20.0300 | Buy Now |
|
|
ComSIT USA | LF-2.7 GHZ RF/IF GAIN AND PHASE DETECTOR Analog Circuit, 1 Func, BIPolar, PDSO14 RoHS: Not Compliant |
|
|
RFQ | |
|
|
Vyrian | Other Function Semiconductors | 18135 |
|
RFQ | |
|
|
Win Source Electronics | IC DETECT GAIN PHASE 14-TSSOP | 3000 |
|
$17.8990 / $26.8480 | Buy Now |
Part Details for AD8302ARU
AD8302ARU CAD Models
AD8302ARU Part Data Attributes
|
|
AD8302ARU
Analog Devices Inc
Buy Now
Datasheet
|
Compare Parts:
AD8302ARU
Analog Devices Inc
LF-2.7 GHz RF/IF Gain and Phase Detector
Select a part to compare: |
| Pbfree Code | No | |
| Rohs Code | No | |
| Part Life Cycle Code | Obsolete | |
| Ihs Manufacturer | ANALOG DEVICES INC | |
| Part Package Code | TSSOP | |
| Package Description | TSSOP-14 | |
| Pin Count | 14 | |
| Manufacturer Package Code | RU-14 | |
| Reach Compliance Code | not_compliant | |
| HTS Code | 8542.39.00.01 | |
| Samacsys Manufacturer | Analog Devices | |
| Analog IC - Other Type | ANALOG CIRCUIT | |
| JESD-30 Code | R-PDSO-G14 | |
| JESD-609 Code | e0 | |
| Length | 5 mm | |
| Moisture Sensitivity Level | 1 | |
| Number of Functions | 1 | |
| Number of Terminals | 14 | |
| Operating Temperature-Max | 85 °C | |
| Operating Temperature-Min | -40 °C | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | TSSOP | |
| Package Equivalence Code | TSSOP14,.25 | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE, THIN PROFILE, SHRINK PITCH | |
| Peak Reflow Temperature (Cel) | 240 | |
| Qualification Status | Not Qualified | |
| Seated Height-Max | 1.2 mm | |
| Supply Voltage-Max (Vsup) | 5.5 V | |
| Supply Voltage-Min (Vsup) | 2.7 V | |
| Supply Voltage-Nom (Vsup) | 5 V | |
| Surface Mount | YES | |
| Technology | BIPOLAR | |
| Temperature Grade | INDUSTRIAL | |
| Terminal Finish | TIN LEAD | |
| Terminal Form | GULL WING | |
| Terminal Pitch | 0.65 mm | |
| Terminal Position | DUAL | |
| Width | 4.4 mm |
Alternate Parts for AD8302ARU
This table gives cross-reference parts and alternative options found for AD8302ARU. The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of AD8302ARU, but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.
| Part Number | Manufacturer | Composite Price | Description | Compare |
|---|---|---|---|---|
| AD8302ARUZ-REEL7 | Analog Devices Inc | Check for Price | SPECIALTY ANALOG CIRCUIT, PDSO14, TSSOP-14 | AD8302ARU vs AD8302ARUZ-REEL7 |
| AD8302ARU-REEL7 | Analog Devices Inc | Check for Price | IC SPECIALTY ANALOG CIRCUIT, PDSO14, TSSOP-14, Analog IC:Other | AD8302ARU vs AD8302ARU-REEL7 |
| AD8302ARUZ-REEL | Analog Devices Inc | Check for Price | LF-2.7 GHz RF/IF Gain and Phase Detector | AD8302ARU vs AD8302ARUZ-REEL |
| AD8302ARUZ | Analog Devices Inc | $21.5052 | LF-2.7 GHz RF/IF Gain and Phase Detector | AD8302ARU vs AD8302ARUZ |
| AD8302ARUZ-RL7 | Analog Devices Inc | $22.3459 | LF-2.7 GHz RF/IF Gain and Phase Detector | AD8302ARU vs AD8302ARUZ-RL7 |
AD8302ARU Frequently Asked Questions (FAQ)
-
A good PCB layout for the AD8302ARU involves keeping the input and output traces short and away from each other, using a solid ground plane, and placing decoupling capacitors close to the device. A 4-layer PCB with a dedicated ground plane is recommended.
-
To ensure accurate gain and phase measurements, it's essential to calibrate the AD8302ARU using a known reference signal. This involves applying a calibrated signal to the input and adjusting the device's gain and phase settings accordingly. Regular recalibration is recommended to maintain accuracy.
-
The AD8302ARU can handle input powers up to +15 dBm (31.6 mW) without damage. However, it's recommended to limit the input power to +10 dBm (10 mW) or less to ensure optimal performance and prevent overheating.
-
The AD8302ARU is rated for operation from -40°C to +85°C. While it can tolerate high temperatures, it's essential to ensure proper heat sinking and airflow to prevent overheating, especially in high-temperature environments.
-
The AD8302ARU can be interfaced with a microcontroller or FPGA using a serial interface (SPI or I2C). The device's output can be connected to an ADC or a digital input pin, and the microcontroller or FPGA can then read the output data and perform further processing.
