LC2CMOS, Quad 8-Bit Voltage Output DAC

Part Details for AD7226KNZ by Analog Devices Inc

Results Overview of AD7226KNZ by Analog Devices Inc

Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.

Applications Education and Research Environmental Monitoring Internet of Things (IoT) Industrial Automation Computing and Data Storage Aerospace and Defense Healthcare Agriculture Technology Medical Imaging Telecommunications Automotive

AD7226KNZ Information

AD7226KNZ by Analog Devices Inc is a Digital to Analog Converter.
Digital to Analog Converters are under the broader part category of Converters.

A converter is an electrical circuit that transforms electric energy into a different form that will support a elecrical load needed by a device. Read more about Converters on our Converters part category page.

Price & Stock for AD7226KNZ

Part # Distributor Description Stock Price Buy
DISTI # 49AK9388
Newark Dac, 8Bit, Dip-20, -40 To 85Deg C, Resolution (Bits):8Bit, Sampling Rate:-, Data Interface:Parall... el, Supply Voltage Range:11.4V To 16.5V, 14.25V To 15.75V, Adc/Dac Case Style:Dip, No. Of Pins:20Pins, Input Channel Type:Single Endedrohs Compliant: Yes |Analog Devices AD7226KNZ more RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 0 Container: Bulk 4
  • 1 $77.1300
  • 5 $70.8900
  • 10 $64.6500
  • 36 $58.4100
  • 54 $55.7000
$55.7000 / $77.1300 Buy Now
DISTI # AD7226KNZ-ND
DigiKey IC DAC 8BIT V-OUT 20DIP Min Qty: 1 Lead time: 10 Weeks Container: Tube 65
In Stock
  • 1 $83.2300
  • 18 $67.0189
  • 36 $64.7267
  • 108 $61.8946
$61.8946 / $83.2300 Buy Now
DISTI # 584-AD7226KNZ
Mouser Electronics Digital to Analog Converters - DAC CMOS DAC IC RoHS: Compliant 98
  • 1 $69.6500
  • 10 $55.4000
$55.4000 / $69.6500 Buy Now
DISTI # V36:1790_06210971
Arrow Electronics DAC 4-CH R-2R 8-bit 20-Pin PDIP N Tube RoHS: Compliant Min Qty: 18 Package Multiple: 18 Lead time: 10 Weeks Date Code: 2316 Americas - 18
  • 18 $55.2700
$55.2700 Buy Now
Analog Devices Inc CMOS DAC IC Package Multiple: 18 607
  • 1 $69.6500
  • 1,000 $35.0200
$35.0200 / $69.6500 Buy Now
DISTI # 26108712
Verical DAC 4-CH R-2R 8-bit 20-Pin PDIP N Tube RoHS: Compliant Min Qty: 18 Package Multiple: 18 Americas - 594
  • 18 $55.2700
$55.2700 Buy Now
DISTI # 81734476
Verical DAC 4-CH R-2R 8-bit 20-Pin PDIP N Tube RoHS: Compliant Min Qty: 18 Package Multiple: 18 Date Code: 2316 Americas - 18
  • 18 $55.2700
$55.2700 Buy Now
DISTI # 69674292
Verical DAC 4-CH R-2R 8-bit 20-Pin PDIP N Tube RoHS: Compliant Min Qty: 10 Package Multiple: 10 Date Code: 2316 Americas - 10
  • 10 $119.7450
$119.7450 Buy Now
DISTI # AD7226KNZ
TME IC: D/A converter, 8bit, 143ksps, Ch: 4, 11.4÷16.5V, DIP20 Min Qty: 1 0
  • 1 $81.3000
  • 3 $70.1000
  • 10 $54.6000
$54.6000 / $81.3000 RFQ
DISTI # AD7226KNZ
Richardson RFPD CONVERTER - DAC RoHS: Compliant Min Qty: 18 0
  • 18 $64.5800
  • 25 $61.9200
  • 100 $60.2700
  • 500 $58.7100
  • 1,000 $57.9600
$57.9600 / $64.5800 Buy Now
Vyrian Converters 108
RFQ

Part Details for AD7226KNZ

AD7226KNZ CAD Models

  • Part Symbol

    Part Symbol

  • Footprint

    footprint

  • 3D Model

    3D Model

Available Download Formats

Sign in to download CAD models Register or Sign In

By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy

AD7226KNZ Part Data Attributes

Parametric Data
AD7226KNZ Analog Devices Inc
Buy Now Datasheet
Compare Parts:
AD7226KNZ Analog Devices Inc LC2CMOS, Quad 8-Bit Voltage Output DAC
Select a part to compare:
Pbfree Code No
Rohs Code Yes
Part Life Cycle Code Not Recommended
Ihs Manufacturer ANALOG DEVICES INC
Part Package Code DIP
Package Description ROHS COMPLIANT, PLASTIC, MS-001, DIP-20
Pin Count 20
Manufacturer Package Code N-20
Reach Compliance Code compliant
ECCN Code EAR99
HTS Code 8542.39.00.01
Samacsys Manufacturer Analog Devices
Analog Output Voltage-Max 10 V
Analog Output Voltage-Min
Converter Type D/A CONVERTER
Input Bit Code BINARY, OFFSET BINARY
Input Format PARALLEL, 8 BITS
JESD-30 Code R-PDIP-T20
JESD-609 Code e3
Length 26.16 mm
Linearity Error-Max (EL) 0.1953%
Negative Supply Voltage-Nom -5 V
Number of Bits 8
Number of Functions 1
Number of Terminals 20
Operating Temperature-Max 85 °C
Operating Temperature-Min -40 °C
Package Body Material PLASTIC/EPOXY
Package Code DIP
Package Equivalence Code DIP20,.3
Package Shape RECTANGULAR
Package Style IN-LINE
Qualification Status Not Qualified
Seated Height-Max 5.33 mm
Settling Time-Max 20 µs
Settling Time-Nom (tstl) 3 µs
Supply Current-Max 13 mA
Supply Voltage-Nom 15 V
Surface Mount NO
Technology CMOS
Temperature Grade INDUSTRIAL
Terminal Finish Matte Tin (Sn)
Terminal Form THROUGH-HOLE
Terminal Pitch 2.54 mm
Terminal Position DUAL
Width 7.62 mm
