10-Bit, Integrated, Multiformat SDTV/HDTV Video Decoder and RGB Graphics Digitizer
Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.
Part # | Distributor | Description | Stock | Price | Buy | |
---|---|---|---|---|---|---|
DISTI #
ADV7181CWBSTZ-ND
|
DigiKey | IC VIDEO DECODER SDTV RGB 64LQFP Min Qty: 1 Lead time: 10 Weeks Container: Tray |
30 In Stock |
|
$15.8754 / $22.2000 | Buy Now |
DISTI #
584-ADV7181CWBSTZ
|
Mouser Electronics | Video ICs 10-bit SD/HD Decoder in 64-pin PKG RoHS: Compliant | 118 |
|
$15.8500 / $22.1900 | Buy Now |
DISTI #
26635496
|
Verical | Video Decoder 4 ADC 10bit Automotive AEC-Q100 64-Pin LQFP Tray RoHS: Compliant Min Qty: 43 Package Multiple: 43 | Americas - 3655 |
|
$14.6026 / $16.7500 | Buy Now |
|
Rochester Electronics | ADV7181C - 10-Bit, Integrated, Multiformat SDTV/HDTV Video Decoder and RGB Graphics Digitizer RoHS: Compliant Status: Active Min Qty: 1 | 10836 |
|
$14.1200 / $16.6100 | Buy Now |
|
ComSIT USA | 10-BIT, INTEGRATED, MULTIFORMAT SDTV VIDEO DECODER AND RGB GRAPHICS DIGITIZER Color Signal Decoder, PQFP64 RoHS: Compliant | Europe - 480 |
|
RFQ |
By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy
|
ADV7181CWBSTZ
Analog Devices Inc
Buy Now
Datasheet
|
Compare Parts:
ADV7181CWBSTZ
Analog Devices Inc
10-Bit, Integrated, Multiformat SDTV/HDTV Video Decoder and RGB Graphics Digitizer
|
Pbfree Code | No | |
Rohs Code | Yes | |
Part Life Cycle Code | Active | |
Ihs Manufacturer | ANALOG DEVICES INC | |
Part Package Code | QFP | |
Package Description | 10 X 10MM, ROHS COMPLIANT, MS-026BCD, LQFP-64 | |
Pin Count | 64 | |
Manufacturer Package Code | ST-64-2 | |
Reach Compliance Code | compliant | |
ECCN Code | EAR99 | |
HTS Code | 8542.39.00.01 | |
Samacsys Manufacturer | Analog Devices | |
Consumer IC Type | COLOR SIGNAL DECODER | |
JESD-30 Code | S-PQFP-G64 | |
JESD-609 Code | e3 | |
Length | 10 mm | |
Moisture Sensitivity Level | 3 | |
Number of Functions | 1 | |
Number of Terminals | 64 | |
Operating Temperature-Max | 85 °C | |
Operating Temperature-Min | -40 °C | |
Package Body Material | PLASTIC/EPOXY | |
Package Code | LFQFP | |
Package Equivalence Code | QFP64,.47SQ,20 | |
Package Shape | SQUARE | |
Package Style | FLATPACK, LOW PROFILE, FINE PITCH | |
Peak Reflow Temperature (Cel) | 260 | |
Qualification Status | Not Qualified | |
Seated Height-Max | 1.6 mm | |
Supply Voltage-Max (Vsup) | 3.45 V | |
Supply Voltage-Min (Vsup) | 3.15 V | |
Surface Mount | YES | |
Temperature Grade | INDUSTRIAL | |
Terminal Finish | Matte Tin (Sn) | |
Terminal Form | GULL WING | |
Terminal Pitch | 0.5 mm | |
Terminal Position | QUAD | |
Time@Peak Reflow Temperature-Max (s) | 30 | |
Width | 10 mm |
