811-S1-003-10-016101 Information
811-S1-003-10-016101 by PRECI-DIP SSA is a Header and Edge Type Connector.
Headers and Edge Type Connectors are under the broader part category of Connectors.
Connectors are devices that join electrical termination points to form circuits. With various types designed for specific functions like data, power, or signal transmission, choosing the right connector is essential for compatibility and device performance. Read more about Connectors on our Connectors part category page.
Price & Stock for 811-S1-003-10-016101
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
811-S1-003-10-016101-ND
|
DigiKey | CONN SPRING PISTON 3POS PCB Min Qty: 410 Lead time: 11 Weeks Container: Bulk | Temporarily Out of Stock |
|
$1.9122 | Buy Now |
|
DISTI #
437-811S100310016101
|
Mouser Electronics | Headers & Wire Housings 7mm 3P Spring-Loaded SLC Conn 2.54mm SR Straight solder tail RoHS: Compliant | 0 |
|
$1.7800 / $1.9100 | Order Now |
|
|
Onlinecomponents.com | RoHS: Compliant | 0 |
|
$1.6700 / $2.4300 | Buy Now |
|
DISTI #
811-S1-003-10-016101
|
Avnet Abacus | Conn Spring Loaded Connector HDR 3 POS 254mm Solder ST ThruHole Box (Alt: 811-S1-003-10-016101) RoHS: Compliant Min Qty: 410 Package Multiple: 410 Lead time: 20 Weeks, 0 Days | Abacus - 0 |
|
Buy Now |
Part Details for 811-S1-003-10-016101
811-S1-003-10-016101 CAD Models
811-S1-003-10-016101 Part Data Attributes
|
|
811-S1-003-10-016101
PRECI-DIP SSA
Buy Now
Datasheet
|
Compare Parts:
811-S1-003-10-016101
PRECI-DIP SSA
Board Connector, 3 Contact(s), 1 Row(s), Male, Straight, 0.1 inch Pitch, Solder Terminal, Locking, ROHS COMPLIANT
Select a part to compare: |
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | PRECI-DIP SA | |
| Package Description | ROHS COMPLIANT | |
| Reach Compliance Code | compliant | |
| Samacsys Manufacturer | Preci-Dip | |
| Additional Feature | LOW PROFILE | |
| Body Breadth | 0.1 inch | |
| Body Depth | 0.22 inch | |
| Body Length | 0.3 inch | |
| Connector Type | BOARD CONNECTOR | |
| Contact Finish Mating | GOLD (10) | |
| Contact Finish Termination | Gold (Au) | |
| Contact Gender | MALE | |
| Contact Material | BERYLLIUM COPPER | |
| Contact Pattern | RECTANGULAR | |
| Contact Resistance | 10 mΩ | |
| Contact Style | RND PIN-SKT | |
| DIN Conformance | NO | |
| Durability | 50000 Cycles | |
| Filter Feature | NO | |
| IEC Conformance | NO | |
| Insulation Resistance | 10000000000 Ω | |
| JESD-609 Code | e4 | |
| MIL Conformance | NO | |
| Mating Contact Pitch | 0.1 inch | |
| Mixed Contacts | NO | |
| Mounting Option 1 | LOCKING | |
| Mounting Style | STRAIGHT | |
| Mounting Type | BOARD | |
| Number Of Connectors | ONE | |
| Number Of PCB Rows | 1 | |
| Number of Rows Loaded | 1 | |
| Operating Temperature-Max | 125 °C | |
| Operating Temperature-Min | -55 °C | |
| Option | GENERAL PURPOSE | |
| PCB Contact Pattern | RECTANGULAR | |
| Rated Current (Signal) | 3.5 A | |
| Reference Standard | UL | |
| Terminal Length | 0.118 inch | |
| Terminal Pitch | 2.54 mm | |
| Termination Type | SOLDER | |
| Total Number of Contacts | 3 | |
| UL Flammability Code | 94V-0 |
